Check Wheel RPM - The wheel should rotate slowly at approximately 53 rpm. If rota-
tion is not normal, see the wheel maintenance information that follows. Perform ser-
vice as needed and/or replace any defective parts.
Wheel Maintenance - How often the wheel needs to be cleaned depends on its
environment. Because the wheel rotates between two opposing airstreams, it is self-
FOHDQLQJRIPRVWGU\GLUWDQGGXVWDQGZLOOUHPDLQHI¿FLHQWIRUDORQJSHULRGRIWLPH
However, when the wheel is exposed to oils, tars, or greases in either the supply or
exhaust airstream, the surface will become “sticky” and will hold the dirt and dust.
Over time the air passages will become blocked causing loss of recovery, excessive
pressure drop, and loss of energy savings.
According to the manufacturer, a wheel operating in a “clean” environment may not
require annual cleaning, but a wheel in a “contaminated” environment may require
PXOWLSOHFOHDQLQJVD\HDUWRPDLQWDLQDLUÀRZDQGUHFRYHU\7KHVHJPHQWHGGHVLJQ
of the wheel not only provides for easier cleaning but also allows for replacement of
individual dirty segments. (See replacement P/N’s on page 30).
The energy recovery wheel including power exhaust is an integral part of the system.
Energy Recovery Wheel
Optional
Preheat
Elements
Exhaust Damper
Outside
Air
Sensor
Power
Exhaust
FIGURE 20 - Energy
Recovery Wheel
Removing, Cleaning, and Replacing Wheel Segments - The segments are the
“heat exchangers” of the energy recovery wheel. Segments must be handled with
care and should never be dropped. Segments may require “slight” persuasion during
LQVWDOODWLRQDQGUHPRYDOEXW1(9(5EHIRUFHGRUEDQJHGZLWKDKDPPHURUVLPLODU
tool.
Instructions:
Ƒ Turn off power to the unit and lock the disconnect switch open.
Ƒ Slide the wheel cassette out of the cabinet (refer to illustration, page 4) NOTE:
Some models may require the removing of a sheet metal blockoff in order to
access the energy recovery wheel.
Remove the wheel segments (from the pulley side of the wheel)
Ƒ 5RWDWHWKHZKHHOWRSRVLWLRQWKH¿UVWVHJPHQWWREHUHPRYHGDWWKHWRS2QERWK
sides of the segment, unlock and open the two retaining straps.
Ƒ Using hand pressure only and supporting the segment, from the motor side
push the wheel segment. On the pulley side, lift the segment out of the spokes.
/D\GRQRWGURSWKHVHJPHQWRQDÀDWVXUIDFH
Ƒ Rotate the wheel so that the segment on the opposite side is on the top. Repeat
WKHSURFHGXUHDQGUHPRYHWKHVHJPHQW&RQWLQXHWKHSURFHGXUHRINHHSLQJWKH
EDODQFHGRSHQDQG¿OOHGVHJPHQWVRSSRVLWHHDFKRWKHUDQGUHPRYHDOORIWKH
segments.
