RF SOLUTIONS Hornet-S2 User Manual

Advanced Operation
Advanced OperationAdvanced Operation
Advanced Operation
To pair a new transmitter switch follow this procedure
To pair a new transmitter switch follow this procedureTo pair a new transmitter switch follow this procedure
To pair a new transmitter switch follow this procedure
Any transmitter button can be configured to operate any of the receiver relays.
Pair any Transmitter switch with a receiver relay by following this procedure:
1. Select the receiver output relay to learn to:
2. Briefly press the receiver Pairing switch (S2) once
3. The Learn LED will flash once to indicate relay 1 is selected
4. After the LED stops flashing, press the Learn switch again to select the next
relay channel
5. Repeat step 4 until the required relay is selected.
6. Press the button on the transmitter you want to learn to the relay.
7. The Learn LED will flash to indicate Pairing is complete.
Pairing a Transmitter to a Receiver
Pairing a Transmitter to a ReceiverPairing a Transmitter to a Receiver
Pairing a Transmitter to a Receiver
The only limitation is that each receiver has a maximum memory for up to 40 pairings,
these can be from the same or any number of transmitters.
Erasing Receivers Memory
Erasing Receivers Memory Erasing Receivers Memory
Erasing Receivers Memory
1. Press and hold the receiver Learn Switch for approx 10 seconds.
2. When the Learn LED turns ON all memory is erased
NOTE:
NOTE:NOTE:
NOTE: You cannot erase individual Tx encoders
Configuring Relays
Configuring Relays Configuring Relays
Configuring Relays
The jumper links set the outputs to be Momentary (operates as long as transmitter is
operated)
or Latching (Relay changes state each time transmitter is pressed).
The jumper links are made / removed by the small link ‘cap’ placed over the pin header.
See Fig 1.1 for location of jumper pins.
Link Positions
Link PositionsLink Positions
Link Positions Relays
RelaysRelays
Relays
LK1
LK1LK1
LK1 LK2
LK2LK2
LK2 RLY 1
RLY 1RLY 1
RLY 1 RLY 2
RLY 2RLY 2
RLY 2 RLY 3
RLY 3RLY 3
RLY 3 RLY 4
RLY 4RLY 4
RLY 4
Closed Closed Mom Mom Mom Mom
Closed Open Mom Mom Latch Latch
Open Closed Mom Latch Latch Latch
Open Open Latch Latch Latch Latch
