S5
S5
S6
S6
Option (For TV with A“Bump”)
3
Option (Potential Cable Blockage)
4
09
S0 S4
S0 S4
8
9
S0 S4
S5
S5
8
8
8
S6
Option (For Flat Back TV)
08
Select installation method according to TV
STEP 3
1
Option (For Round Back TV or Curved TV)
2
S0 S4
Please make sure the
brackets 、 are
vertically centered and
level with each other.
98
Select TV Screw Length
STEP 2
When attaching brackets to the TV, be careful not to over tighten screws
and be sure that screws don't bottom out in the mounting holes.
Please make sure the length of thread engagement at least 6 turns or
5/16 inch (8mm).
Spacers may be necessary for 2 holes ONLY.
Spacers may be necessary when cables or
plug/outlets are blocked by brackets.
To Next Page
