602400011500
Revision C
Page 15 of 24
AlarmPinout:
Pin No. Alarm Configuration
1 Low Pressure Normally Closed (NC)
2 Low Pressure Common (COM)
3 Low Pressure Normally Open (NO)
4 High Pressure Normally Closed (NC)
5 High Pressure Common (COM)
6 High Pressure Normally Open (NO)
7 Humidity Normally Closed (NC)
8 Humidity Common (COM)
9 Humidity Normally Open (NO)
10 Run Time Normally Closed (NC)
11 Run Time Common (COM)
12 Run Time Normally Open (NO)
Picture 5.5 – APD-D Series Site Grounding Studs
 Site Grounding Studs:
   


       
     
     
      
      


   

6 MAINTENANCE
     
    
     
     
 



6.1 Taking the Unit Out of Service and
RemovingtheLid:
 

      
    

 

 

 

 
 
       


Picture 6.1 – Lid Removal and Filter Location
 
       

