SYSTEM ASSEMBLY
45
* Note: Item 22 (Part No 220307 - Valve Pressure Relief ½” Caleffi Clip In 312004) and one unit of item 6 (Part
No 088100 - Spring Clip for Relief Valve Caleffi) are supplied with the solar storage tank.
30
344573
Connector assembly tank to OTP valve
-
-
1
-
1
31
209000
Valve OTP thermosiphon arrestor TA705 ¾
-
-
1
-
1
32
330606
Copper blanking disc
2
2
2
2
2
33
341515
Plug thumb G1/8 M & O-ring assembly
-
-
1
-
1
34
344593
Adaptor G3/8” x BSP to ISO7 R¼”
-
-
1
-
1
35
341504
Adaptor Tee clip in port to ISO7 RP¼ & O-ring
-
-
1
-
1
36
337144
Tank to collector spacer
2
2
2
3
3
37
331658
Union Body R ¾ M x G ½ M Olive
1
1
1
1
1
38
204600
Collector strap
2
2
2
3
3
39
344185
Reservoir tank 2 collectors
-
-
1
-
-
39
344186
Reservoir tank 3 collectors
-
-
-
-
1
not shown
331844
Drive cleat
-
-
-
1
1
not shown
337093
Extension pipe assembly systems
-
-
-
2
1
not shown
347187
Instruction to attach fill / drain label
1
1
1
1
1
not shown
347199
Instruction 52H S3 OTP installation
-
-
1
-
1
