Rheem 80PS12EDR

30
BLOWER PERFORMANCE DATA – DOWNFLOW MODELS
50K
11 x 6
[279 x 152]
11 x 6
[279 x 152]
11 x 7
[279 x 178]
11 x 7
[279 x 178]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
1/2
[373]
1/2
[373]
1/2
[373]
1/2
[373]
1/2
[373]
3/4
[559]
LOW 735 [347] 715 [337] 690 [326] 660 [311] 635 [300] 605 [286] 575 [271]
MED-LO 1025 [484] 1015 [479] 995 [470] 975 [460] 955 [451] 930 [439] 905 [427]
MED-HI 1185 [559] 1165 [550] 1150 [543] 1130 [533] 1100 [519] 1075 [507] 1040 [491]
HIGH 1345 [635] 1330 [628] 1310 [618] 1295 [611] 1265 [597] 1235 [583] 1205 [569]
LOW 1210 [571] 1205 [569] 1195 [564] 1180 [557] 1165 [550] 1155 [545] 1130 [533]
MEDIUM 1580 [746] 1560 [736] 1550 [732] 1530 [722] 1495 [706] 1465 [691] 1430 [675]
HIGH 1915 [904] 1880 [887] 1825 [861] 1790 [845] 1740 [821] 1675 [791] 1600 [755]
LOW 1070 [505] 1055 [498] 1040 [491] 1010 [477] 980 [477] 945 [446] 905 [427]
MEDIUM 1240 [585] 1210 [571[ 1190 [562] 1165 [550] 1135 [536] 1095 [517] 1055 [498]
HIGH 1420 [670] 1395 [658] 1370 [647] 1340 [632] 1305 [616] 1265 [597] 1220 [576]
LOW 1303 [615] 1304 [615] 1280 [604] 1250 [590] 1222 [577] 1188 [561] 1160 [547]
MEDIUM 1697 [801] 1674 [790] 1655 [781] 1638 [773] 1621 [765] 1581 [746] 1542 [728]
HIGH 2078 [981] 2068 [976] 2037 [961] 2010 [949] 1988 [938] 1938 [915] 1898 [896]
LOW 1690 [798] 1670 [788] 1655 [781] 1615 [762] 1585 [748] 1565 [739] 1525 [720]
MEDIUM — 2085 [984] 2055 [970] 2005 [946] 1970 [930] 1945 [918] 1880 [887]
HIGH — 2410 [1137] 2355 [1111] 2305 [1088] 2240 [1057] 2165 [1022] 2100 [991]
LOW 1104 [521] 1081 [510] 1050 [496] 1025 [484] 999 [471] 971 [458] 940 [444]
MEDIUM 1284 [606] 1269 [599] 1236 [583] 1206 [569] 1179 [556] 1139 [538] 1102 [520]
HIGH 1478 [698] 1438 [679] 1397 [659] 1362 [643] 1392 [657] 1282 [605] 1242 [586]
75K
75K
100K
100K
100K
11 x 10
[279 x 254]
11 x 10
[279 x 254]
3/4
[559]
3/4
[559]
LOW — 1690 [798] 1660 [783] 1635 [772] 1580 [746] 1535 [724] 1480 [698]
MEDIUM — 2090 [986] 2035 [960] 1985 [937] 1930 [911] 1850 [837] 1785 [842]
HIGH — 2395 [1130] 2335 [1102] 2260 [1067] 2185 [1031] 2080 [982] 1965 [927]
LOW 1675 [791] 1650 [779] 1620 [765] 1570 [741] 1545 [729] 1485 [701] 1425 [673]
MEDIUM 2105 [993] 2075 [979] 2035 [960] 1990 [939] 1955 [923] 1900 [897] 1815 [857]
HIGH — — — — — — —
120K
150K
3
3
4
3
5
5.5
5
5
INPUTTONS
BLOWER
SIZE
[mm]
MOTOR
H.P.
[W]
BLOWER
SPEED
.1 [.02] .2 [.05] .3 [.07] .4 [.10] .5 [.12] .6 [.15] .7 [.17]
CFM [L/s] AIR DELIVERY
EXTERNAL STATIC PRESSURE INCHES [kPa] WATER COLUMN
IMPORTANT: Airflow must be checked at the return and the furnace outlet ahead of the coil.
NOTES: Airflow external static pressure does not include filter or coil.
Note: Recommended blower speeds are in bold.
BLOWER PERFORMANCE DATA – UPFLOW/HORIZONTAL MODELS
IMPORTANT: Airflow must be checked at the return and the furnace outlet ahead of the coil.
NOTES: Airflow external static pressure does not include filter or coil.
50K
11 x 6
[279 x 152]
11 x 7
[279 x 178]
11 x 7
[279 x 178]
11 x 7
[279 x 178]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
1/2
[373]
1/2
[373]
1/2
[373]
1/2
[373]
1/2
[373]
3/4
[559]
3/4
[559]
3/4
[559]
LOW 675 [319] 655 [309] 635 [300] 610 [288] 585 [276] 555 [262] 520 [245]
MED-LO 950 [448] 930 [439] 905 [427] 880 [415] 860 [406] 830 [392] 800 [380]
MED-HI 1115 [526] 1090 [514] 1070 [505] 1040 [491] 1015 [479] 985 [465] 945 [446]
HIGH 1270 [599] 1250 [590] 1225 [578] 1200 [566] 1165 [550] 1130 [533] 1085 [512]
LOW 1245 [588] 1220 [576] 1195 [564] 1165 [550] 1135 [536] 1105 [522] 1065 [503]
MED 1555 [734] 1515 [715] 1475 [696] 1435 [677] 1395 [658] 1350 [637] 1300 [614]
HIGH 1810 [854] 1755 [838] 1705 [805] 1645 [776] 1585 [748] 1530 [722] 1470 [694]
LOW 1050 [496] 1040 [491] 1030 [486] 990 [467] 960 [453] 920 [434] 890 [420]
MED 1220 [576] 1195 [564] 1160 [547] 1140 [538] 1105 [522] 1065 [503] 1020 [481]
HIGH 1410 [665] 1380 [651] 1345 [635] 1300 [614] 1255 [592] 1205 [569] 1150 [543]
LOW 1295 [611] 1275 [602] 1250 [590] 1225 [578] 1195 [564] 1165 [550] 1135 [536]
MED 1645 [776] 1615 [762] 1580 [746] 1550 [732] 1510 [713] 1465 [691] 1425 [672]
HIGH 2045 [965] 2000 [944] 1955 [923] 1905 [899] 1845 [871] 1785 [842] 1720 [812]
LOW 1645 [776] 1615 [762] 1580 [746] 1550 [732] 1510 [713] 1465 [691] 1425 [673]
MED 2045 [965] 2000 [944] 1955 [923] 1905 [899] 1845 [871] 1785 [842] 1720 [812]
HIGH 2320 [1095] 2260 [1067] 2200 [1038] 2130 [1005] 2060 [972] 1985 [937] 1910 [901]
LOW 1645 [776] 1635 [772] 1615 [762] 1590 [750] 1560 [736] 1520 [717] 1470 [694]
MED 2050 [967] 2015 [951] 1980 [934] 1935 [913] 1885 [890] 1835 [866] 1775 [838]
HIGH 2365 [1116] 2310 [1090] 2250 [1062] 2185 [1031] 2115 [998] 2035 [960] 1950 [920]
LOW 1620 [765] 1595 [753] 1570 [741] 1545 [729] 1515 [715] 1480 [698] 1440 [680]
MED 2010 [949] 1985 [937] 1960 [925] 1915 [904] 1850 [873] 1800 [850] 1730 [816]
HIGH 2340 [1104] 2275 [1074] 2215 [1045] 2145 [1012] 2080 [982] 2010 [949] 1940 [916]
LOW 1093 [563] 1066 [503] 1039 [490] 1008 [476] 977 [461] 941 [444] 905 [427]
MED 1241 [586] 1212 [572] 1183 [558] 1150 [543] 1118 [528] 1076 [508] 1033 [487]
HIGH 1393 [657] 1359 [642] 1326 [626] 1293 [610] 1259 [594] 1214 [573] 1169 [552]
75K
75K
100K
100K
100K
120K
150K
3
3
4
3
4.5
5
5
5
INPUTTONS
BLOWER
SIZE
[mm]
MOTOR
H.P.
[W]
BLOWER
SPEED
.1 [.02] .2 [.05] .3 [.07] .4 [.10] .5 [.12] .6 [.15] .7 [.17]
CFM [L/s] AIR DELIVERY
EXTERNAL STATIC PRESSURE INCHES [kPa] WATER COLUMN
Note: Recommended blower speeds are in bold.
