49
TABLE 8
ALTERNATE METHOD FOR CANADIAN HIGH-ALTITUDE DERATE
IMPORTANT: 90 Plus Models only. Do not use this chart for any 80 Plus Models
NATURAL GAS LP GAS
FIGURE 46
MANIFOLD PRESSURE-CHANGE LABEL
THE MANIFOLD PRESSURE OF THIS APPLIANCE HAS
BEEN FIELD ADJUSTED TO OBTAIN THE CORRECT
INPUT RATING FOR INSTALLATION AT ALTITUDES
BETWEEN 2,000 FEET AND 4,500 FEET ELEVATION.
LA PRESSION DU DISTRIBUTEUR D'ALIMENTATION
DE CET APPAREIL A ÉTÉ AJUSTÉ SUR LES LIEUX AFIN
D'OBTENIR LA BONNE PUISSANCE D'ENTRÉE POUR
UNE INSTALLATION ENTRE 2000 ET 4500 PIEDS
D'ALTITUDE.
92-24399-01-01
LP GAS AT HIGH ALTITUDE
ELEVATIONS
ORIFICE INSTALLATION
LP Gas is a manufactured gas that has
consistent heating value across most
regions.
The NFGC guidelines are used with the
following exception:
The recommended LP Gas high altitude
orifice selections differ slightly in that the
NFGC LP orifice chart, as they are not
accurate for Rheem products. The
National Fuel Gas Code LP orifices are
based on an 11⬙ of water column
pressure at the orifice, which differs from
Rheem products that use 10⬙ of water
column at the orifice. This difference
requires a deviation from the NFGC
orifice size recommendations. The Sea
Level input should still be reduced by 4%
per thousand ft. and the orifice size must
be selected based on the reduced input
selection Table 7.
ALTITUDE
INPUT
OUTPUT
ORIFICE
S
IZE
MANIFOLD
P
RESSURE
0’ - 2000’
45,000
6
0,000
75,000
90,000
105,000
120,000
40,500
5
4,000
67,500
81,000
94,500
108,000
#50
3.5” W.C.
2001’ - 4500’
40,500
54,000
67,500
81,000
94,500
108,000
36,450
48,600
60,750
72,900
85,050
97,200
#50
3.0” W.C.
ALTITUDE
INPUT
OUTPUT
ORIFICE
SIZE
MANIFOLD
PRESSURE
0’ - 2000’
45,000
60,000
75,000
90,000
105,000
120,000
40,500
54,000
67,500
81,000
94,500
108,000
1.15mm
10” W.C.
2001’ - 4500’
40,500
54,000
67,500
81,000
94,500
108,000
36,450
48,600
60,750
72,900
85,050
97,200
1.15mm
7.6” W.C.
ORIFICE ORDERING INFORMATION
Orifice sizes are selected by adding the
2-digit drill size required in the orifice
p
art number. Drill sizes available are 39
through 64; metric sizes available
1.10mm (-90) and 1.15mm (-91):
Orifice Part Number 62-22175-(drill
size)
E
xample 1:
# 60 drill size orifice required
Part # 62-22175-60
Example 2:
1.15mm drill size orifice required
P
art # 62-22175-91
ALTERNATE METHOD FOR
CANADIAN
HIGH-ALTITUDE
DERATE
In Canada, unless an orifice change is
specifically mandated by local codes,
an alternate method of altitude deration
through a reduction in manifold
pressure is acceptable as described in
Table 8.
The information in Table 8 is based
on a heating value of 1000 BTU per
cubic feet of natural gas, and 2500
BTU per cubic feet of LP gas.
I
MPORTANT: Actual input rates must
be measured on-site with manifold
p
ressure adjustment to ensure that an
actual 10% reduction in input rate is
achieved.
Once this field adjustment has been
made, the label shown in Figure 46
m
ust be affixed in a conspicuous
location on the front of the furnace
cabinet:
NOTE: This label is supplied in the
information packet shipped with each
f
urnace.
TABLE 7
L
P GAS ORIFICE DRILL SIZE
(4% PER 1000 FT DE-RATE)
IMPORTANT: 90 Plus Models only. Do not
use
this chart for any 80 Plus Models
Input (per
Altitude burner) 15000 Orifice Size
0 to 2000 ft. 15000 1.15 mm
(factory)
2000ⴕ-3000ⴕ 13200 1.15 mm
3000ⴕ-4000ⴕ 12600 1.10 mm
4000ⴕ-5000ⴕ 12000 #58
5000ⴕ-6000ⴕ 11400 #59
6000ⴕ-7000ⴕ 10800 #60
7000ⴕ-8000ⴕ 10200 #62
8000ⴕ-9000ⴕ 9600 #63
9000ⴕ-10000ⴕ 9000 #64
