FIGURE 6
CLEARANCE TO COMBUSTIBLES, UPFLOW UNITS
8
UPFLOW MODELS MINIMUM CLEARANCE (IN.)
LEFT RIGHT SHIP
MODEL A B C D E F
SIDE SIDE
BACK TOP FRONT VENT
WGTS
04 17
1
/2 16
11
/32 15
5
/8 21513
25
/32 00012*0 111
06 17
1
/2 16
11
/32 15
5
/8 21513
25
/32 00012*0 117
07 17
1
/2 16
11
/32 15
5
/8 21513
25
/32 00012*0 123
09 21 19
27
/32 19
1
/8 218
1
/217
9
/32 00012*0 148
10 21 19
27
/32 19
1
/8 218
1
/217
9
/32 00012*0 152
12 24
1
/2 23
11
/32 22
5
/8 22220
25
/32 00012*0 160
I392
➤*A service clearance of at least 24 inches is recommended in front of all furnaces.

Rheem RGRA SERIES Specifications

General

Efficiency	Up to 96% AFUE
Type	Gas Furnace
Ignition System	Direct Spark Ignition
Installation Options	Upflow, Downflow, Horizontal
Fuel Type	Natural Gas or Propane
Configuration	Multi-Position
Ignition	Direct Spark
Heat Exchanger	Stainless Steel
Vent Type	PVC
Warranty	Limited Lifetime Heat Exchanger, 10-Year Parts
Stages	Single or Two-Stage
