12
F
IGURE 7
CLEARANCE TO COMBUSTIBLES, HORIZONTAL UNITS
I520
HORIZONTAL MODELS MINIMUM CLEARANCE (IN.)
LEFT RIGHT SHIP
MODEL A B C D E F
SIDE SIDE
BACK TOP FRONT VENT
WGTS
06 17
1
2 16
11
32 15
5
8 2 16
5
8 13
7
8 0 0 0 1 2* 0 117
07A 17
1
2 16
11
32 15
5
8 2 16
5
8 13
7
8 0 0 0 1 2* 0 123
07B 21 19
27
32 19
3
16 2 20
1
8 17
3
8 0 0 0 1 2* 0 123
09 21 19
27
32 19
3
16 2 20
1
8 17
3
8 0 0 0 1 2* 0 148
10 21 19
27
32 19
3
16 2 20
1
8 17
3
8 0 0 0 1 2* 0 152
12 24
1
2 23
11
32 22
5
8 2 23
5
8 20
7
8 0 0 0 1 2* 0 160
*A service clearance of at least 24 inches is recommended in front of all furnaces.
NOTE: In horizontal configuration, return air cutout is not permitted.
Horizontal left-hand airflow only.
IMPORTANT: This furnace is not approved or recommended for
installation on its back, with access doors facing upwards.
AIRFLOW
DRAIN TRAP LOCATION
SUPPLY
AIR
RETURN AIR
A103601.DGN
2 DIA.
GAS
CONNECTION
2 DIA.
ALT. GAS
CONNECTION
4
3
8
25
13
16
