Rheem RSNM SERIES User Manual

25
ELECTRICAL DATA
XVI. MISCELLANEOUS
-A024JK -A030JK -A036CK -A036JK -A042CK -A042JK -A048CK -A048JK -A060CK -A060JK
Unit Operating
Voltage Range
187-253 187-253 187-253 187-253 187-253 187-253 187-253 187-253 187-253 187-253
Minimum Circuit
Ampacity
20/20 21/21 20/20 26/26 22/22 27/27 24/24 32/32 28/28 41/41
Minimum Overcurrent
Protection Device Size
25/25 25/25 25/25 30/30 25/25 35/35 30/30 40/40 35/35 50/50
Maximum Overcurrent
Protection Device Size
30/30 35/35 30/30 40/40 30/30 40/40 35/35 50/50 40/40 60/60
No. 1111111111
Volts 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230
Phase 1131313131
HP 2 2.5 3 3 3.5 3.5 4 4 4.5 4.5
RPM 3450 3450 3450 3450 3450 3450 3450 3450 3450 3450
Amps (RLA) 13.5/13.5 14.1/14.1 12.8/12.8 17/17 13.5/13.5 17.9/17.9 14.7/14.7 21.2/21.2 16/16 26.4/26.4
Amps (LRA) 54/54 73/73 95/95 96.7/96.7 88/88 112/112 115/115 115/115 110/110 134/134
No. 1111111111
Volts 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230
Phase 1111111111
HP 1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3
Amps (FLA) 1.5 1.5 1.5 1.5 1.5 1.5 1.9 1.9 1.9 1.9
Amps (LRA) 3 3 3 3 3 3 4 4 4 4
No. 1111111111
Volts 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230
Phase 1111111111
HP 1/4 1/3 1/2 1/2 1/2 1/2 3/4 3/4 3/4 3/4
Amps (FLA) 1.5 1.8 2.5 2.5 2.8 2.8 3.2 3.2 5.8 5.8
Amps (LRA) 2.5 2.6 4.9 4.9 4.3 4.3 4.1 4.1 9 9
Evaporator Fan
ELECTRICAL DATA - RSNM SERIES
Unit InformationCompressor MotorCondenser Motor
