Rheem RSNM SERIES User Manual

5
FIGURE 1
UNIT DIMENSIONS AND ACCESS LOCATIONS
Model
024, 030, 036
042, 048, 060
Height “A”
29 1/8"
37 1/8"
024, 030, 036, 042
048, 060
2
11
/16"
[266.7 mm]
59"
[1498.6 mm]
53
1
/2"
[1358.9 mm]
3
1
/16"
[77.7 mm]
A
CONTROL
BOX ACCESS
2
11
/16"
[266.7 mm]
CONDENSATE
DRAIN
PAN
ACCESS
FRONT VIEW
BOTTOM VIEW
ELECTRICAL CONNECTIONS
PRIMARY
HIGH VOLTAGE
ENTRANCE
1
23
/32" [43.7 mm]
4
13
/32"
[111.8 mm]
5
9
/64"
[130.5 mm]
19
7
/8"
[505 mm]
5
7
/8"
[149.5 mm]
3
1
/2"
[88.9 mm]
3
3
/4"
[95.3 mm]
7
21
/32"
[194.3 mm]
3
13
/64"
[81.2 mm]
AUXILIARY
HIGH VOLTAGE
ENTRANCE
1
23
/32" [43.7 mm]
LOW VOLTAGE
ENTRANCE
7
/8" [22.2 mm]
RECOMMENDED UNIT
DISCONNECT LOCATION
