7 / 15
Locate an appropriate place on a section of wall as above mentioned.
Fig 1 Front and back of the appliance
Fig 2 Drill two holes of 6.00mm diameter: if you install the heater upright above the sink, the
distance between every two holes is 146mm; if you install the heater upside down under the sink, the
distance between every two holes is 139mm. Put plastic anchor in the holes
Fig2-A: Upward Installation Fig2-B: Upside down Installation
