RHEONIK Messgeräte GmbH REV. I, Apr. 2004
.
Operation Manual RHE 07, 08, 11 Page 22
Note:
Care should be taken to ensure that the flow has been completely stopped before using the input for
zeroing..
- Using the Reset function, the input can be used to start a batching process in combina-
tion with totalizer limit outputs.
- Without installed I/O board inside the transmitter RHM the input function has to be
programmed as Not used.
2.1.3.6.4. Contact outputs
The output hardware is the same as for frequency output (see section 2.1.3.6.1.).
All outputs can be programmed as follows:
- Limit Flow, Temp, Dens:
Flow rate, temperature or density limit. The output is active below the adjusted setting.
- Limit Mass:
Mass totalizer limit. The output is active below the adjusted totalizer value.
- Error:
Output is activated when a malfunction in the flowmeter occurs or is detected.
- Flow Direc:
Flow direction output. Output is active in one flow direction and passive in the opposite.
- Empty Tube:
Empty tube signal is active, if no liquid is inside the meter tubes.
