7
PRE-INSTALLATION CHECK
PLEASE READ THROUGH THE ENTIRE INSTRUCTION MANUAL
BEFORE COMMENCING THE INSTALLATION
Before beginning installation, the following needs to be identified:
1. Upper Bulkhead location (where the vehicle has an inner and outer metal skin with a gap
between the two) for the Top Restraint Hinge (H).
2. Mid Bulkhead location (where the vehicle has an inner and outer metal skin with a gap between
the two) for the Mid Rail Brace (G).
3. Location of the mounting points. It is extremely important that the Floor, Mid and Top Restraints
do not interfere with any of the vehicles control systems, Brake lines, wiring, fuel lines or any
components critical for the vehicles operation.
1114
955
926
850
1314
146
75
420
SHELVING UNIT OVERVIEW
Front ViewFront View Side ViewSide View
Adjustable height end panelAdjustable height end panel
Top ViewTop View
MaximumMaximum
MinimumMinimum
