18
BRANCHEMENTS ÉLECTRIQUES
K code AC07069
K-CRX code AC07068
F
M
LED
R=2K2
ALIMENTATION
230Vac 50 Hz
SPARK
230Vac 40W
OUVRE
ANTENNE
COMMUN
COMMUN
PIETON
PAS A PAS
BUZZER
+
+
-
BARRE PALPEUSE
PHOTOCELLULES
FERME
AUTOTEST POUR BARRE PALPEUSE
ACCESSOIRES
24Vdc 0,4A ± 15%
24Vdc 0,4A ± 15%
+
-
