DL9 or DL10 OFF Faulty safety edge (In case the edge is not connected, carry
out jumper between COM A+ and EDGE 1/EDGE 2)
LED DL13 (BLUE) ON Some functions are enabled via smartphone, so via
smartphone check the card functions as the dips/trimmers status may not be true.
On the board there are resettable fuses which intervene in the event of a short circuit,
interrupting the output assigned to them.
In the event of troubleshooting, it is advisable to disconnect all the removable
connectors and insert them one at a time in order to more easily identify the cause
of the fault.
TABLE SUMMARISING VISUAL AND SOUND ALARMS
SIGNALS DURING PROGRAMMING SEQUENCE
EVENT BUZZER STATUS FLASHER STATUS DL1 LED STATUS
Dip 1 ON (hold-to-run mode)
Or failure of a safety device
Off Off Flashes on-off 250 ms
Dip 2 ON (full stroke programming) Off Off Flashes on-off 500 ms
Dip 2>1 ON (pedestrian stroke programming) Off Off Flashes on-off 500 ms
Programming sequence stopped due to intervention of a safety device 10 seconds tone with 2 seconds pause Off On steady
EVENT BUZZER STATUS FLASHER STATUS DL12 LED STATUS
No transmitter code entered Off Off Flashes intermittently red/green
Dip 1 > 2 - transmitter code programming for full opening Off Off Flashes red for 10 seconds
Dip 1 > 3 - transmitter code programming for pedestrian opening Off Off Flashes green for 10 seconds
Dip 1>2> 3 - transmitter code programming for R-AUX relay Off Off Flashes orange for 10 seconds
Correct transmitter codes programming for full opening and R-AUX relay 1 Tone Off Turns green once
Correct transmitter codes programming for pedestrian opening 1 Tone Off Turns red once
Remote control code not present in memory Off Off Turns red once
Memory saturated by remote control codes (1000 codes saved) Off Off Runs 6 green flashes
Radio code deletion for full opening, pedestrian opening, R-AUX relay 2 Tones Off Runs 2 green flashes
WARNING SIGNALS DURING OPERATION
EVENT BUZZER STATUS FLASHER STATUS LED STATUS AND SIGNAL OUTPUT
Stop button pressed Off Off Led DL6 turns off
Photocell intervention 1 Tone Off Led DL7-8 turns off
Edge intervention 2 Tones Off Led DL9-10 turns off
Failure of a safety device or safety device engaged for too long Off Off Led DL1 flashes on-off 250 ms
Alarm from edge 2 Tones every 5 seconds for 1 minute
(It is renewed by giving a command)
Enabled for 1 minute No led combined
Failed photocells auto-test alarm 4 Tones every 5 seconds for 1 minute
(It is renewed by giving a command)
Off No led combined
Functional block activated by smartphone Off Off Led DL12 is steady on green.
Achievement of set cycles 6 Tones every 5 seconds
(It is renewed by giving a command)
Off No leds matched
Energy saving activated by smartphone Off Off Blue led flashes once every 5 seconds
Alarm from Self-learning failed Continuous tone for 10 seconds with
2-second pause.
Not active when DIP 2 in OFF
Off No leds matched
