47
D
ELEKTROANSCHLÜSSE
M
ANTENNE
433 MHz
ANTENNE
ZOPFFLECHTEN
SCHLIEßEN
ÖFFNEN
GEMEINSAM
BLINKER
230Vac 40W
STROMVERSORGUNG
230Vac 50 Hz
ZEITGESTUERTE ÖFFNUNG
ÖFFNEN 2
SCHLIEßEN
OK SCHLIEßEN
EINZELIMPULS
ÖFFNEN 1
24Vdc 0,4A ±15%
24Vdc 0,4A ±15%
A+TEST / A-
AUTOTEST
FOTOZELLEN
LED
R=2,2K 1/4W
ENSCHALTER SCHLIESSEN
ENSCHALTER ÖFFNEN
ENDSCHALTER LANGSAM SCHLIEßEN
ENDSCHALTER LANGSAM ÖFFNEN
GEMEINSAMER ERDUNGSKONTAKT
FOTOZELLEN 1
STOP
MAGNETWINDUNGSENSOR BEI EINGANG
FOTOZELLEN 2
KONTAKTLEISTE
GEMEINSAMER ERDUNGSKONTAKT
GEMEINSAMER ERDUNGSKONTAKT
GEMEINSAM
700 W MAX
