RELAY AND MOTOR COMMAND
POINT B - SETTINGS
DIP 1 (ON) MOTOR ROTATION DIRECTION CHECK
(See Point C)
DIP 2 (ON) PROGRAMMING (See Point D)
DIP 1-2 STORING/ERASING RADIO CODES FOR
MOTOR CONTROL (only CRX control board)
(See Point E)
DIP 3
DIP 4
DIP 5
DIP 6
WARNING: The PARK MODE enables or disables some features and
commands:
If NORMAL MODE is enabled, OPEN2 command, OK CLOSE
command and TLC (Traffic Light Control) input, are not
enabled.
If PARK MODE is enabled all commands are enabled.
DIP 7
DIP 8
DIP 9
DIP 10
DIP 11
DIP 12 OFF - Operation control with low speed limit switches
connected separately LIMIT SWITCHES FIXED ON THE
BALANCE SPRING BARS (for PARK control panel)
ON - Operation control with low speed limit switches
connected in parallel LIMIT SWITCHES FIXED ON THE
DRIVING SHAFT (the low speed wire can be connected
to LSSC or LSSO)
DIP 13
DIP 14
DIP 15
DIP 16
LOW SPEED REGULATOR
LED WARNING
POINT C - CALIBRATING LOW SPEED MOTOR
Turn DIP1 to ON
Press the PROG button
WARNING:
Turn DIP1 to OFF
During Point C procedure the safety-strip and photocells are not
enabled.
POINT D - TIME PROGRAMMING
Turn the DIP 2 to ON
Press the PROG button
Press the PROG button
Turn DIP2 to OFF.
During Point D procedure, the safety devices (photocells and safety
strip) are active.
POINT E - RADIO CODE STORING (ONLY FOR CRX)
(MAX 60 CODES)
Turn DIP1 to ON
turn also DIP2 to ON position
Turn DIP1 to OFF
Turn DIP2 to OFF
POINT F - RADIO CODE ERASING (ONLY FOR CRX)
Turn DIP1 to ON
turn also DIP2 to ON
Press the PROG button
