SAFETY STRIP SELF-TEST ALARM (DIP 9 ON)
STOP BUTTON (COM - STOP)
FUNCTIONING IN DEAD MAN MODE WHEN THE SAFETY DEVICES
ARE FAILING
Note 1:
Note 2:
The dead-man operation is only an emergency operation which
must be activated for a very short period and with the complete
installation at sight so to have a secure and safe control of the
system. As soon as possible however, the failing safety devices
must be repaired and activated.
BLINKER 230V 40W
BUZZER (Optional) (COM-BUZZER)
GATE OPEN WARNING LIGHT (COM-SIGNAL)
N.B.:
DIP 12 - CONTROLLING SLOW-DOWN
OFF -
LIMIT SWITCHES FIXED ON THE
BALANCE SPRING BARS (for PARK control panel)
ON -
LIMIT SWITCHES FIXED ON THE
DRIVING SHAFT (the low speed wire can be connected to
LSSC or LSSO)
TECHNICAL FEATURES
RADIO TECHNICAL FEATURES (ONLY FOR CRX)
A
B
