Rich Solar MPPT Series User Manual

238
173
6X 8
Φ
72.5
72.5
168
123.5
RS-MPPT30/RS-MPPT40
Product dimensions: 238*173*72.5mm
Hole positions: 180*147mm
Hole diameter: Φ3mm
Applicable wire: max. 8 AWG
22
180
147
4X 4.5Φ
4X 10Φ
151
210
59.5
131
154
4X 9Φ
4X 4.5Φ
8
59.5
6X 7
Φ
9.3
17
143.6
111
RS-MPPT20
Product dimensions: 210*151*59.5mm
Hole positions: 154*131mm
Hole diameter: Φ3mm
Applicable wire: max. 8 AWG
8. PRODUCT DIMENSIONS
8/ PRODUCT DIMENSIONS
-7.1 12V System Conversion Efficiency
Conversion efficiency（%）
MPPT 12V conversion efficiency (12V battery)
Output power（W）
-7.1 24V System Conversion Efficiency
MPPT 24V conversion efficiency (24V battery)
Output power（W）
7. CONVERSION EFFICIENCY CURVE
7/ CONVERSION EFFICIENCY CURVE
96%
95%
94%
93%
92%
91%
90%
89%
88%
87%
550 525 500 475 450 425 400 375 350 300 250 200 150 100 50
Conversion efficiency（%）
98%
96%
94%
92%
90%
88%
86%
1100 1000 900 800 600 500 300 100
20 Vmp
40 Vmp
60 Vmp
75 Vmp
40 Vmp
50 Vmp
60 Vmp
75 Vmp
16
15
