Ricoh Aficio MP C3001/C3501 and MP C4501/C5501
System Specifications
General Specifications
Specifications for MP C4501/C5501 are the same for
MP C4501A/C5501A except where indicated
Configuration Desktop Color Laser MFP
Printing Process Dry Electrostatic Transfer with
Dual Component Magnetic Brush
Development; 4-Drum Method
Scanning Technology 1D Solid Scanning via CCD
Output Speed MP C3001: 30-ppm BW & FC (LTR)
(Copy/Print) MP C3501: 35-ppm BW & FC (LTR)
MP C4501: 45-ppm BW & FC (LTR)
MP C5501: 55-ppm BW & FC (LTR)
Warm-Up Time MP C3001/C3501: <23 seconds
MP C4501: <22 seconds
MP C5501: <36 seconds
MP C4501A: <24 seconds
MP C5501A: <38 seconds
Recovery from MP C3001/C3501: <13 seconds
Sleep Mode MP C4501: <19 seconds
MP C5501: <32 seconds
First Copy Time MP C3001/C3501: 7.8/4.9 seconds
(FC/BW) MP C4501: 5.9/3.7 seconds
MP C5501: 5.0/3.1 seconds
Copy Resolution 600 dpi
Quantity Indicator Up to 999 copies
Document Feeder
MP C3001/C3501 Original Capacity: 50 sheets
Automatic Reversing Original Size: 5.5” x 8.5” –
Document Feeder 11” x 17”
(ARDF) Paper Weight:
Simplex: 11 – 34 lb.Bond
(40 – 128 g/m
2
)
Duplex: 14 – 28 lb. Bond
(52 – 105 g/m
2
)
MP C4501/C5501 Original Capacity: 100 sheets,
Automatic Reversing Original Size: 5.5” x 8.5” –
Document Feeder 11”x 17”,
(ARDF) Paper Weight:
Simplex:11 – 34 lb. Bond
(40 – 128 g/m
2
)
Duplex:14 – 34 lb. Bond
(52 – 128 g/m
2
)
MP C4501A/C5501A Original Capacity: 100 sheets
Single Pass Duplexing Original Size: 5.5” x 8.5” –
Feeder (SPDF) 11” x 17”
Paper Weight:
Simplex:11 – 34 lb. Bond
(40 – 128 g/m
2
)
Duplex:14 – 34 lb. Bond
(52 – 128 g/m
2
)
Paper Capacity Standard: 2 x 550 sheets + 100-
sheet Bypass Tray, Maximum: 4,400
sheets (w/Tandem LCT + Side LCT)
Standard Paper Sizes 1st Paper Tray: 8.5” x 11”
2nd Paper Tray: 7.25” x 10.5” –
11” x 17”, Envelopes (with option)
Bypass: Up to 12” x 18”, Envelopes
Custom Sizes: Width: 3.5” – 12”
(90-305mm), Length: 5.8” – 49.6”
(148-1260mm): Over 600mm
requires SP mode
Standard Paper Standard Trays: 16 – 68 lb.
Weights Bond/140 lb. Index (60 – 256 g/m
2
)
Bypass Tray: 16 –
80 lb. Bond/110 lb.
Cover (60 – 300 g/m
2
)
Duplex Unit: 16 – 45 lb. Bond/90 lb.
Index (60 – 169 g/m
2
)
Paper Types Plain/recycled paper, laser printer
qualified transparencies, labels,
envelopes
Auto Duplex Standard
Output Capacity Standard (all): 500 sheets,
Face Down
Maximum: MP C3001/C3501: 1,625
sheets (w/1,000-sheet Finisher + 1
Bin Tray) MP C4501/C5501: 3,625
sheets (w/3,000 Sheet Finisher
+ 1 Bin Tray)
Zoom 25% – 400% in 1% increments
Preset Reduction 93%, 85%, 78%, 73%, 65%,
50%, 25%
Preset Enlargement 400%, 200%, 155%, 129%, 121%
Dimensions (WxDxH) MP C3001/C3501: 26.4” x 26.5”
x 30” (670 x 671 x 760mm)
(standard configuration, does not
include document feeder)
MP C4501/C5501: 26.4” x 26.7”
x 30” (670 x 677 x 760mm)
(standard configuration, does not
include document feeder)
Weight MP C3001/C3501: <264 lb.
(120kg) w/ARDF
MP C4501/C5501: <287 lb.
(130kg) w/ARDF
MP C4501A/C5501A: <293 lb.
(133kg) w/SPDF
Power Requirements 120V – 127V, 60Hz
Power Consumption 1,584 Watts or less
TEC Value MP C3001: 1620Wh
MP C3501: 1830Wh
MP C4501: 2630Wh
MP C5501: 3510Wh
Printer Controller Specifications (Standard)
CPU MP C3001/C3501: Intel Celeron-M
@ 600 MHz, Embedded
MP C4501/C5501: Intel Celeron-M
@ 1.0 GHz, Embedded
Memory MP C3001/C3501: 1.5 GB RAM
Standard/Maximum; 160 GB
Hard Disk Drive
MP C4501/C5501: 2 GB RAM
Standard/Maximum; 160 GB
Hard Disk Drive
Max. Print Speed MP C3001: 30ppm BW & FC
MP C3501: 35ppm BW & FC
MP C4501: 45ppm BW & FC
MP C5501: 55ppm BW & FC
Print Drivers Standard: PCL 5c, PCL 6 (XL),
XPS via download
Optional: Adobe Postscript 3
Font Support Standard: PCL: 45 Scalable, 6
Bitmapped + 13 International fonts
Optional: PostScript 3: 136 Roman
fonts, IPDS: 108 Roman fonts
Max. Print Resolution 1200 x 1200 dpi
Network Interfaces Standard: 10BaseT/100Base-TX
Ethernet (RJ-45), Dual USB 2.0
Host Interfaces (for external device
connection), USB 2.0 Hi Speed (for
direct PC/Mac connection)
Optional: Gigabit Ethernet
(1000Base-T)
IEEE 802.11a/b/g Wireless Interface
IEEE 1284/ECP Parallel Interface
Front USB 2.0/SD Card Slot
Interface
Network Protocol TCP/IP (IPv4, IPv6), IPX/SPX
Support
Network/OS Windows 2000/XP/Vista/7/Server
2003/Server 2008/Server 2008R2,
Mac OS X 10.2 or later, Novell
NetWare 6.5, UNIX filters for Sun
Solaris, HP-UX, SCO OpenServer,
RedHat Linux, and IBM AIX, SAP
R/3, NDPS Gateway, IBM iSeries
– AS/400 using OS/400 Host Print
Transform
Utilities Web SmartDeviceMonitor
SmartDeviceMonitor, Web Image
Monitor, @Remote, Print Utility for
Mac (w/Adobe PS3 option)
Scanner Specifications (Standard)
Scanner Resolution BW and FC scanning at 100 – 600
dpi, Up to 1200 dpi for TWAIN
scanning only (BW/FC)
Default Scan Resolution: 200 dpi
Scanning Speed MP C3001/C3501: 200dpi: 51ipm
(Letter-size) BW/FC; 300dpi: 47ipm BW / 41ipm FC
MP C4501/C5501:
300dpi: 67ipm BW/FC
MP C4501A/C5501A: 300dpi:
85-ipm BW/FC Simplex / 116-ipm
BW/FC Duplex
Scan Area Main Scan: 11.7” (297mm)
Sub Scan: 17” (432mm)
sRGB Support Standard
Scan Mode BW Text/Line Art, BW Text,
BW Text/Photo, BW Photo, BW
Grayscale FC Photo, FC Text, Auto
Color Selection (ACS)
Compression Method BW: TIFF (MH, MR, MMR)
Grayscale/FC Color: JPEG
Supported File Single/Multi-Page TIFF,
Formats Single Page JPEG
Single/Multi-Page PDF, High
Compression PDF
Scan-to Modes Scan-to-Email (with LDAP support)
Scan-to-Folder (SMB/FTP/NCP)
Scan-to-URL
Scan-to-Media (USB/SD Card)
(requires option)
Network TWAIN Scanning
Document Server Specifications (Standard)
Total Hard Disk 160 GB (Shared with other
Drive Capacity functions)
Max. Stored 3,000 documents
Documents
Max. Pages per 2,000 pages
Document
Max. Page Capacity 9,000 pages
Facsimile Specifications (Optional)
Type Fax Option Type C5501; Super G3
Transceiver
Circuit PSTN, PBX
Resolution 200 x 100 dpi, 200 x 200 dpi,
400 x 400 dpi (with optional SAF
memory)
Modem Speed 33.6K – 2,400 bps w/Auto Fallback
Compression Method MH, MR, MMR, JBIG
Transmission Speed G3: Approximately 2 seconds/page
(w/JBIG); G3: Approximately 3
seconds/page (w/MMR)
Scanning Speed MP C3001/C3501: 49ipm
(Letter LEF) MP C4501/C5501: 68ipm
MP C4501A/C5501A: 74ipm
Auto Dialing 2,000 Quick/Speed Dial numbers;
100 Group Dial numbers (500
locations per Group)
Additional Fax Modes Internet Fax (T.37), IP Fax (T.38),
LAN Fax, Fax Forwarding to E-mail/
Folder, LDAP Support
Memory Capacity Standard: 4 MB (approx. 320 pages),
(SAF) Optional: 28 MB (approx. 2,240
pages) with optional SAF memory
Additional Modes Internet Fax by E-mail (T.37); IP Fax
(T.38); LAN Fax; Fax Forward to
E-mail/Folder; LDAP Support
Options Additional G3 Lines (up to 2); Fax
SAF Memory; Telephone Handset
Security Features (Standard)
DataOverwriteSecurity System (DOSS), HDD Encryption, User
Code Account Limits, Network Protocol On/Off, IP Filtering,
SNMP v3 Support, Encryption (Address Book, Authentication
Password, Locked Print Password, PDF, SSL Communication,
S/MIME, IPsec Communication), Locked (Secure) Print, User
Authentication (Windows/LDAP with Kerberos- External; Basic
and User Codes- Internal), 802.1.x Wired Authentication,
WPA/WPA2 (Wi-Fi Protect Access Support), Classification
Codes, and more
Security Features (Optional)
Copy Data Security, DataOverwriteSecurity System (DOSS)
with ISO 15408 Common Criteria Certification
Hardware Accessories
Paper Handling Options
Two-Tray Paper Bank (PB3100)
1
All Models
Tray Capacity 1,100 sheets (550 sheets x 2 trays)
Paper Size 5.8” x 8.3” to 11” x 17”
Paper Weight 16 – 68 lb. Bond/140 lb. Index
(60 – 256 g/m
2
)
Dimensions (WxDxH) 22.8” x 24.4” x 10.2”
(580 x 620 x 260mm)
Weight Less than 57 lb. (26kg)
One-Tray Paper Bank (PB3080)
1
MP C3001/C3501 only
Tray Capacity 550 sheets x 1 tray
Paper Size 5.8” x 8.3” to 11” x 17”
Paper Weight 16 – 68 lb. Bond/140 lb. Index
(60 – 256 g/m
2
)
Dimensions (WxDxH) 22.8” x 24.4” x 4.7”
(580 x 620 x 120mm)
Weight Less than 33 lb. (15kg)
Requires installation of Caster Table Type A
Tandem Large Capacity Tray (PB3110)
1
All Models
Tray Capacity 2,000 sheets (1,000 sheets x 2)
Paper Size 8.5” x 11”
Paper Weight 16 – 68 lb. Bond/140 lb. Index
(60 – 256 g/m
2
)
Dimensions (WxDxH) 22.8” x 24.4” x 10.2”
(580 x 620 x 260mm)
Weight Less than 57 lb. (26kg)
FAC33 Cabinet Stand
1
Installs under Standard Paper Trays and provides storage for paper,
toner, etc.
To Next Page
