SYStem SpecificationS
Ricoh Aficio MP C3002/MP C3502
www.ricoh-usa.com
R3321
Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh
®
and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. All other trademarks are the property of their respective owners. The content of this document, and the
appearance, features and specifications of Ricoh products and services are subject to change from time to time without notice. Products are shown with optional features. While care
has been taken to ensure the accuracy of this information, Ricoh makes no representation or warranties about the accuracy, completeness or adequacy of the information contained
herein, and shall not be liable for any errors or omissions in these materials. Actual results will vary depending upon use of the products and services, and the conditions and factors
affecting performance. The only warranties for Ricoh products and services are as set forth in the express warranty statements accompanying them.
General Specifications
Printing Process 4-Drum Method
Output Speed MP C3002: 30-ppm BW & FC (LTR)
(Copy/Print) MP C3502: 35-ppm BW & FC (LTR)
Warm-Up Time MP C3002/C3502: 20 seconds
Recovery from MP C3002/C3502: 7.8 seconds
Sleep Mode
First Copy Time MP C3002/C3502: 7.3/4.8 seconds
(FC/BW)
Copy Resolution 600 dpi
Quantity Indicator Up to 999 copies
Document Feeder
Automatic Reversing Original Capacity: 50 sheets
Document Feeder Original Size: 5.5" x 8.5" – 11" x 17"
(ARDF) (A5 – A3)
Paper Weight:
Simplex: 11 – 34 lb. Bond (40 – 128 g/m
2
)
Duplex: 14 – 28 lb. Bond (52 – 105 g/m
2
)
Paper Capacity Standard: 2 x 550 sheets + 100-sheet
Bypass Tray, Maximum: 4,400 sheets
(w/Tandem LCT + Side LCT)
Supported Paper Sizes 1st Paper Tray: 8.5" x 11" (A4)
2nd Paper Tray: 7.25" x 10.5" – 11" x 17",
Envelopes (with option) (up to A3)
Bypass: Up to 12" x 18", Envelopes (A3)
Custom Sizes: Width: 3.5" – 12" (90 – 305
mm), Length: 5.8" – 23.6" (148 – 600 mm)
Supported Paper Standard Trays: 16 – 68 lb. Bond/
Weights 140 lb. Index (52 – 256 g/m
2
)
Bypass Tray: 16 – 80 lb. Bond/
110 lb. Cover (52 – 300 g/m
2
)
Duplex Unit: 16 – 45 lb. Bond/
90 lb. Index (52 – 169 g/m
2
)
Paper Types Plain/recycled paper, laser printer qualified
transparencies, labels, envelopes
Auto Duplex Standard
Output Capacity Standard (all): 500 sheets, Face Down
Maximum: MP C3002/C3502: 1,625 sheets
(w/1,000-sheet Finisher + 1 Bin Tray)
Zoom 25% – 400% in 1% increments
Dimensions (WxDxH) 26.4" x 26.9" x 34.7" (670 x 682 x 880 mm)
Weight < 266 lb. (120 kg) w/ARDF
Power Requirements 120V – 127V, 60Hz
Power Consumption 1,584W or less
TEC Value MP C3002: 1,435Wh
MP C3502: 1,631Wh
Printer Specifications (Standard)
CPU Intel Celeron-M @ 600 MHz, Embedded
Memory 1.5 GB RAM Standard/190 GB HDD
Max. Print Speed MP C3002: 30 ppm BW & FC
MP C3502: 35 ppm BW & FC
Print Drivers Standard: PCL 5c, PCL 6 (XL),
XPS via download
Optional: Postscript 3
Font Support Standard: PCL: 45 Scalable,
6 Bitmapped + 13 International fonts
Optional: PostScript 3: 136 Roman fonts,
IPDS: 108 Roman fonts
Max. Print Resolution 1200 x 1200 dpi
Network Interfaces Standard: 10BaseT/100Base-TX Ethernet
(RJ-45), USB 2.0 Host Interface, USB 2.0
Hi Speed (for direct PC/Mac connection),
Front USB 2.0/SD Card Slot Interface
Optional: Gigabit Ethernet (1000Base-T)
IEEE 802.11a/b/g Wireless Interface
Bluetooth, IEEE 1284/ECP Parallel Interface
Network Protocol Support TCP/IP (IPv4, IPv6), IPX/SPX*
Network/OS Windows XP/Vista/7/Server 2003/Server
2008/Server 2008R2, Mac OS X 10.2 or
later, Novell NetWare 6.5, Sun Solaris,
HP-UX, SCO OpenServer, RedHat Linux,
and IBM AIX, SAP R/3, IBM iSeries
– AS/400 using OS/400 Host Print
Transform
Utilities
Web SmartDeviceMonitor
Web Image Monitor, @Remote
™
Document Server Specifications (Standard)
Max. Stored Documents 3,000 documents
Max. Page Capacity 9,000 pages
Scanner Specifications (Standard)
Scanner Resolution BW and FC scanning at 100 – 600 dpi,
Up to 1200 dpi for TWAIN scanning
Default Scan Resolution: 200 dpi
Scanning Speed 200 dpi: 51 ipm (Letter-size) BW/FC;
300 dpi: 47ipm BW/41 ipm FC
Scan Area 11.7" x 17" (297 mm – 432 mm)
Compression Method BW: TIFF (MH, MR, MMR, JBIG2)
Grayscale/FC Color: JPEG
Supported File Single/Multi-Page TIFF,
Formats Single Page JPEG
Single/Multi-Page PDF,
High Compression PDF, PDF/A
Scan Modes Scan-to-Email (with LDAP support)
Scan-to-Folder (SMB/FTP/NCP*)
Scan-to-URL
Scan-to-Media (USB/SD Card)
Network TWAIN Scanning
*Netware option is required
Facsimile Specifications (Optional)
Type Fax Option Type C5502; Super G3
Resolution 200 x 100 dpi, 200 x 200 dpi, 400 x 400
dpi (with optional SAF memory)
Modem Speed 33.6K – 2,400 bps w/Auto Fallback
Compression Method MH, MR, MMR, JBIG
Transmission Speed G3: Approximately 2 seconds/page (JBIG)
Scanning Speed 49 ipm (Letter LEF)
Auto Dialing 2,000 Quick/Speed Dial numbers;
100 Group Dial numbers
Memory Capacity
Standard: 4 MB (approx. 320 pages),
(SAF)
Optional: 28 MB (approx. 2,240 pages)
with optional SAF memory
Options
Additional G3 Lines (up to 2), Fax
Connection Unit, Fax SAF Memory,
Telephone Handset
Security Features (Standard)
DataOverwriteSecurity System (DOSS), HDD Encryption, User Codes,
SNMP v3 Support, Encryption, Locked Print, User Authentication,
802.1.x Wired Authentication, WPA/WPA2 (Wi-Fi Protect Access
Support), Digitally Signed PDF, and more
Security Features (Optional)
Copy Data Security, DataOverwriteSecurity System (DOSS) with
ISO 15408 Common Criteria Certification
Hardware Accessories
Paper Handling Options
Two-Tray Paper Bank (PB3130)
1
Tray Capacity 1,100 sheets (550 sheets x 2 trays)
Paper Size 5.8" x 8.3" to 11" x 17" (A5 – A3)
Paper Weight 14 – 68 lb. Bond/140 lb. Index (52 – 256 g/m
2
)
Dimensions (WxDxH) 22.8" x 24.4" x 10.2" (580 x 620 x 260 mm)
One-Tray Paper Bank (PB3120)
1
Tray Capacity 550 sheets x 1 tray
Paper Size 5.8" x 8.3" to 11" x 17" (A5 – A3)
Paper Weight 14 – 68 lb. Bond/140 lb. Index (52 – 256 g/m
2
)
Dimensions (WxDxH) 22.8" x 24.8" x 4.7" (580 x 629 x 120 mm)
Requires installation of Caster Table Type D
Tandem Large Capacity Tray (PB3140)
1
Tray Capacity 2,000 sheets (1,000 sheets x 2)
Paper Size 8.5" x 11" (A4)
Paper Weight 14 – 68 lb. Bond/140 lb. Index (52 – 256 g/m
2
)
Dimensions (WxDxH) 22.8" x 24.4" x 10.2" (580 x 620 x 260 mm)
Side Large Capacity Tray (RT3020)
Tray Capacity 1,200 sheets
Paper Size 8.5" x 11" (A4)
Paper Weight 16 – 57.5 lb. Bond/120 lb. Index
(60 – 216 g/m
2
)
Dimensions (WxDxH) 13.7" x 21.3" x 11.4" (348 x 540 x 290mm)
Requires Two-Tray Paper Bank (PB3130) or Tandem LCT (PB3140)
Output Trays & Finisher Options
Internal Shift-Sort Tray (SH3060)
Tray Capacity 250 sheets (8.5" x 11" or smaller) (A4 – A5)
125 sheets (8.5" x 14" or larger) (B4 – A3)
Paper Size 5.5" x 8.5" to 12" x 18" (A6 – A3)
Paper Weight 14 – 80 lb. Bond/110 lb. Cover (52 – 300 g/m
2
)
Cannot be installed with any Finisher or Side Tray
Side Tray Type C5502
Tray Capacity 250 sheets (8.5" x 11" or smaller) (A4 – A5)
125 sheets (8.5" x 14" or larger) (B4 – A3)
Paper Size 5.5" x 8.5" to 12" x 18" (A5 – A3)
Paper Weight 14 – 80 lb. Bond/165 lb. Index (52 – 300 g/m
2
)
Dimensions (WxDxH) 30.7" x 16.2" x 5.4" (780 x 412 x 138 mm)
Cannot be installed with any Finisher or Internal Shift-Sort Tray
500-sheet Finisher (SR3070)
2
Paper Size 5.5" x 8.5" to 11" x 17" (A5 – A3)
Paper Weight 14 – 67 lb. Bond/140 lb. Index (52 – 253 g/m
2
)
Stack Capacity 500 sheets (8.5" x 11" or smaller)
250 sheets (8.5" x 14" or larger)
Staple Paper Size 8.5" x 11" to 11" x 17" (A5 – A3)
Staple Paper Weight 14 – 67 lb. Bond (52 – 253 g/m
2
)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger, and/or
Mixed Sizes)
Staple Positions 1 staple: 4 positions; 2 staples: 1 position
Dimensions (WxDxH) 19.4" x 26.1" x 18.1" (492 x 662 x 460 mm)
1,000-sheet Finisher (SR3090)
2
Paper Size Proof Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Shift Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Paper Weight Proof Tray: 14 – 69 lb. Bond/140 lb. Index
(52 – 260 g/m
2
)
Shift Tray: 14 – 43 lb. Bond/90 lb. Index
(52 – 163 g/m
2
)
Stack Capacity Proof Tray: 250 sheets (8.5" x 11")
50 sheets (8.5" x 14" or larger)
Shift Tray: 1,000 sheets (8.5" x 11")
500 sheets (8.5" x 14" or larger)
Staple Capacity 50 sheets (8.5" x 11")
30 sheets (8.5" x 14" or larger)
Staple Paper Size 8.5" x 11" – 11" x 17" (A5 – A3)
Staple Paper Weight 17 – 24 lb. Bond (64 – 90 g/m
2
)
Staple Positions 1 staple: 2 positions;
2 staples: 1 position
Dimensions (WxDxH) 10.7" x 20.5" x 31.2" (270 x 520 x 790 mm)
1,000-sheet Booklet Finisher (SR3100)
2
Paper Size Proof Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Shift Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Booklet Tray: 8.5" x 11", 8.5" x 14", 11" x 17"
(A6 – A3)
Paper Weight Proof Tray: 14 – 28 lb. Bond (52 – 105 g/m
2
)
Shift Tray: 14 – 68 lb. Bond/140 lb. Index
(52 – 256 g/m
2
)
Booklet Tray: 17 – 24 lb. Bond (64 – 90 g/m
2
)
Stack Capacity Proof Tray: 100 sheets (8.5" x 11" or smaller)
(A5 – A4)
50 sheets (8.5" x 14" or larger) (B4 – A3)
Shift Tray: 1,000 sheets (8.5" x 11") (A4)
500 sheets (8.5" x 14" or larger) (B4 – A3)
100 sheets (5.5" x 8.5") (A5)
Booklet Tray: 20 sets (2 – 5 sheets/set, all
sizes, saddle-stitched) or 10 sets (6 – 10
sheets/set, all sizes, saddle-stitched)
Staple Capacity Normal Staple: 50 sheets (8.5" x 11") (A4)
30 sheets (8.5" x 14" or larger) (B4 – A3)
Saddle Stitch: 10 sheets (up to 40-page
booklets)
Staple Paper Size Normal Staple: 8.5" x 11" to 11" x 17"
(A4 – A3)
Saddle Stitch: 8.5" x 11" to 11" x 17"
(A4, B4, A3)
Staple Paper Weight: 17 – 24 lb. Bond
(64 – 90 g/m
2
)
Staple Positions 1 staple: 2 positions; 2 staples: 3 positions
Dimensions (WxDxH) 21.1” x 23.7” x 36.7” (535 x 600 x 930 mm)
2-/3-Hole Punch Unit Optional; Installs inside Finisher
Punch Paper Sizes: 5.5" x 8.5" to 11" x 17"
Punch Paper Weight: 14 – 43 lb. Bond/
90 lb. Index (52 – 163 g/m
2
)
Additional Accessories
FAC 52 Cabinet Stand, Envelope Feeder, One Bin Tray, File Format
Converter, Key Counter Bracket, Platen Cover, Card Reader Bracket,
Counter Interface, Camera Direct Print Card, ADF Handle, IPDS Unit,
HotSpot Printing Kit, Fiery
TM
Print Controller, Caster Table, Browser Unit,
SD Card for Netware
Consumables
Item Yield
Black Toner 28,000 pages
Cyan Toner 18,000 pages
Magenta Toner 18,000 pages
Yellow Toner 18,000 pages
1
Either the Cabinet Stand or one of the paper options must be installed.
2
Requires configuration with Bridge Unit.
