HVPS
Preparation
M101
• Front cover ( p.43 "M101 Covers")
• Top cover
• Left cover
M102
• Front cover (
p.50 "M102 Covers, Platen Cover, Flatbed Unit")
• Top cover
• Right cover
• Left cover
• Platen cover
• Flatbed unit
M103
• Front cover ( p.60 "M103 Covers, Flatbed Unit, ADF")
• Top cover
4. Replacement and Adjustments
138
