IMAGE FUSING AND PAPER EXIT
B064 Series/B140 Series/G126 6-118 SM
6.12.4 HOT ROLLER CLEANING
Overview
The cleaning web is saturated with silicone oil.
Inside the web cleaning unit, the web take-up roller [A] pulls the web from the web
supply roller [B] past the cleaning roller [C]. The cleaning roller is pressed against
the hot roller.
B140D9A6.WMF
[A]
[C]
[B]
