Ricoh D124 - Major Units Identification

107
MO-C1 Training
Slide 107
Major Units
1. Operation panel/Scanner unit
2. Main unit
3. Roll unit 1 (standard)
4. Roll unit 2 (option)
5. Exit stacker
 The scanner unit and main unit are mounted on separate racks.
 The units can be easily separated for servicing, or for placing the scanner on a
low table or desk so that it can be operated from a sitting position.
