Ricoh D124 - Key Component Details

108
MO-C1 Training
Slide 108
Main Unit Layout - 1
 The operation panel and
scanner unit are mounted
on the scanner stand.
 The main unit is mounted
on the main unit stand.
 The main unit and scanner
stand can be separated
easily.
 Most service procedures
require that the main
unit stand and scanner
stand be separated.
Operation
Panel
Scanner
Unit
Main Unit
Main Unit
Stand
Scanner
Stand
No additional notes
