Paper Feed Path - 1
Roll entrance sensors: When
the user installs a roll, these
sensors detect the leading
edge of the paper that the
user feeds manually. This
triggers the roll feed
sequence and feeds paper
into the vertical feed path.
Pre-registration sensor:
Detects the leading edge of
the roll paper when it is fed
into the vertical paper path.
DRESS sensor: Functions as
a paper registration sensor
when the user installs a new
roll, at the start of a print job,
and after cutting at the end of
a print job.
Roll Entrance
Sensor
Roll Exit
Sensor
Paper Exit
Sensor
Pre-registration
Sensor
DRESS
Sensor
Registration
Standby Position
DRESS: Direct Realization Edge Scanning Sensor
