MO-C1 Training
Slide 129
Paper Feed Path - 3
 There are two standby
positions.
 If Roll Unit 2 or bypass feed
is selected for a job, but
paper from Roll Unit 1 is at
the registration standby
position, the machine
rewinds roll 1 to paper
standby position 1.
 Similarly, if Roll Unit 1 or
bypass feed is selected for a
job when paper from Roll
Unit 2 is at the registration
standby position, the
machine rewinds roll 2 to
paper standby position 2.
 Both the paper standby
positions are 51.5 mm away
from the pre-registration
sensor.
Registration
Standby Position
Paper Standby
Position 1
Paper Standby
Position 2
