MO-C1 Training
Slide 167
Original Width Detection - 1
These sensors detect the width of the original when it is set on
the original table:
Metric version: 10 sensors (9 original width sensors plus the
original set sensor [1], which also functions as a width sensor).
Inch version: 11 sensors (9 original width sensors, the original set
sensor [1], and one additional width sensor [2] to detect 30“).
Original Width Sensor for 30”
Original Set Sensor
