Ricoh GR Digital II Firmware Update Manual

2
2. Extract the firmware
1.
Download the firmware from the Ricoh website.
2. Double-click or right-click and select [Open] on the downloaded file.
• A dialog screen appears.
3. Click [OK].
• The folder [GR DIGITAL 2 Update] is created, and the firmware is extracted to the folder
[Firmware relX.XX (where X.XX is the version number)]. Check that [ylaunch3] (firmware
file) and [ylaunch7] (adjusted value file) are inside the folder [Firmware relX.XX].
3. Copy the firmware to an SD memory card
There are two ways to copy the firmware into an SD memory card.
• With an SD memory card loaded in the camera, connect the camera and computer with the
provided USB cable, and copy the firmware to the SD memory card
• Using a card reader or a card writer, copy the firmware to an SD memory card (a card reader
or card writer is required)
To copy the firmware by connecting the camera and computer with the USB
cable
1. If Caplio Software is installed on your Windows PC, check that RICOH
Gate La is not active.
2. If RICOH Gate La is active, right-click on the RICOH Gate La icon in the
task bar, and click [Exit].
• If the RICOH Gate La icon is not displayed in the task bar, you do not need to perform Step 2.
3. Load a battery with adequate remaining power into the camera.
4. Load the SD memory card into the camera, and turn the power on.
5. Display the camera’s Setup menu, select [Format [Card]], and press the
$ button.
ylaunch3
ylaunch7
ylaunch3
ylaunch7
For Windows For Macintosh

Ricoh GR Digital II Specifications

General

Megapixel	10 MP
Sensor type	CCD
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2592 x 1944, 2736 x 2736, 3264 x 2448, 3648 x 2432, 3648 x 2736
Optical zoom	0 x
Interface	USB2.0, Mini-B cable, Mass storage 8, AV output
Digital SLR	Yes
Power source	DB60
Camera shutter speed	1/30 - 1/2000 s
Effective sensor resolution	1 pixels
Minimum storage drive space	160 MB
Minimum system requirements	Windows Vista, XP, 2000
Focus adjustment	Manual
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (wide)	0.2 - 3 m
Internal memory	54 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	1024 pixels
Product color	Black, Silver
Battery technology	Alkaline
Number of batteries supported	1
Operating temperature (T-T)	0 - 40 °C
Image editing	resizing, rotating
White balance	auto, Cloudy, daylight, flash, Fluorescent, Incandescent, manual
Light metering	Centre-weighted, Spot
Light exposure modes	aperture priority AE, auto, manual

Weight and Dimensions

Depth	25 mm
Width	107 mm
Height	58 mm
Weight	168 g
