Ricoh GR Digital II Firmware Update Manual

3
6. Select [Yes], and press the MENU/OK button.
• The SD memory card is formatted.
Caution
If you format a card that still has images stored on it, the images will be lost. Save the images you do not want to erase in
your computer before formatting the card.
7. Turn the camera off, and connect the camera and computer with the
provided USB cable.
• The camera turns on automatically. If the camera does not turn on automatically, press the
POWER button and turn the power on.
• If Caplio Software is installed in your Windows PC, RICOH Gate La may automatically
start up. In this case, exit RICOH Gate La.
• Click [Cancel] if the [Removable Disk] dialog appears in Windows XP or Windows Vista.
• If iPhoto starts up in Mac OS X, exit iPhoto.
8. Copy the files [ylaunch3] and [ylaunch7] (created when the firmware was
extracted) into [RICOHDCX] root directory in [My Computer].
• The camera’s drive name may differ depending on the OS you are running.
e.g. [Removable Disk], etc.
9. Open [RICOHDCX] in [My Computer], and confirm that the files have been
copied.
ylaunch3
ylaunch7
RICOHDCX
ylaunch3
ylaunch7
For Windows For Macintosh

Ricoh GR Digital II Specifications

General

Megapixel	10 MP
Sensor type	CCD
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1280 x 960, 2048 x 1536, 2592 x 1944, 2736 x 2736, 3264 x 2448, 3648 x 2432, 3648 x 2736
Optical zoom	0 x
Interface	USB2.0, Mini-B cable, Mass storage 8, AV output
Digital SLR	Yes
Power source	DB60
Camera shutter speed	1/30 - 1/2000 s
Effective sensor resolution	1 pixels
Minimum storage drive space	160 MB
Minimum system requirements	Windows Vista, XP, 2000
Focus adjustment	Manual
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (wide)	0.2 - 3 m
Internal memory	54 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.7 \
Display resolution (numeric)	1024 pixels
Product color	Black, Silver
Battery technology	Alkaline
Number of batteries supported	1
Operating temperature (T-T)	0 - 40 °C
Image editing	resizing, rotating
White balance	auto, Cloudy, daylight, flash, Fluorescent, Incandescent, manual
Light metering	Centre-weighted, Spot
Light exposure modes	aperture priority AE, auto, manual

Weight and Dimensions

Depth	25 mm
Width	107 mm
Height	58 mm
Weight	168 g
