Ricoh gr digital III Instruction Manual

2
2. Extract the firmware
1.
Download the firmware from the Ricoh website.
2. Double-click, or right-click and select [Open] on the downloaded file.
• A dialog screen appears.
3. Click [OK].
• The folder [GR DIGITAL 3 Update] is created, and the firmware is extracted to the folder
[Firmware relX.XX (where X.XX is the version number)]. Check that [glaunch3] (firmware
file) and [glaunch8] (adjusted value file) are inside the folder [Firmware relX.XX].
3. Copy the firmware to an SD memory card
There are two ways to copy the firmware into an SD memory card.
• With an SD memory card loaded in the camera, connect the camera and computer with the
provided USB cable, and copy the firmware to the SD memory card
• Using a card reader or a card writer, copy the firmware to an SD memory card (a card reader
or card writer is required)
To copy the firmware by connecting the camera and computer with the USB
cable
1. If DC Software is installed on your Windows PC, check that DL-10 is not
active.
2. If DL-10 is active, right-click on the DL-10 icon in the task bar, and click
[Exit].
• If the DL-10 icon is not displayed in the task bar, you do not need to perform Step 2.
3. Load a battery with adequate remaining power into the camera.
4. Load the SD memory card into the camera, and turn the power on.
5. Display the camera’s setup menu tab, select [Format [Card]], and press
the $ button.
glaunch3
glaunch8
glaunch3
glaunch8
For Windows For Macintosh

Ricoh gr digital III Specifications

General

Megapixel	10 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	No
Image sensor size	1/1.7 \
Maximum image resolution	3648 x 2736 pixels
Optical zoom	5.7 x
Fixed focal length	6 mm
Focal length range	- mm
Digital SLR	-
Minimum RAM	256 MB
Built-in flash	Yes
Minimum processor	500 MHz
Camera shutter speed	- s
Minimum storage drive space	160 MB
Compatible operating systems	Windows 2000, XP, Vista; Mac OS9.0-9.2.2, Mac OSX10.1.2-10.5.6.
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, Auto
Flash modes	auto, Flash off, manual, Red-eye reduction, Slow synchronization
Internal memory	88 MB
Compatible memory cards	SD, SDHC
Maximum memory card size	32 GB
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	3 \
Display resolution (numeric)	- pixels
Scene modes	Documents
Image editing	resizing, rotating
White balance	Auto, Cloudy, Daylight, Fluorescent, Incandescent, Manual
Camera playback	Movie
Self-timer delay	10 s
Product color	Black
Battery technology	Alkaline
Number of batteries supported	2

Weight and Dimensions

Depth	25.5 mm
Width	59.8 mm
Height	108.6 mm
