The GXR remembers shooting settings in both the body and the camera unit. It is
possible to specify in advance which settings are to be used. Select the body
settings if you want to shoot and process images in the same way regardless of the
camera unit. Select the camera unit settings if you want to change settings for
image creation in a style specific to the camera unit. This increases shooting
flexibility and speed by saving the time and effort involved in redoing settings.
The directional pad handles diagonal movement in addition to the standard
up-down and right-left. For example, the directional pad enables smoother and
easier operations for AE/AF target selection, image selection on the micro-thumbnail
display, etc.
The GXR provides three My Settings. In addition, up to six special purpose and
infrequently used My Settings can be saved in a My Settings Box and quickly
assigned to the mode dial as necessary.
Frequently used functions can be assigned to the ADJ. lever. Press at the center to
call up the registered functions and then press to the left or right to select a
function. Use the + or – button to quickly complete the setting. In addition, there
are two Fn buttons to which selected functions can be registered for switching
with one push. Setting changes can be made directly without menu operations.
The GXR has a 3.0-inch, 920,000-dot VGA picture display. A wide color
reproduction range with 100% sRGB coverage gives a high-reality image for both
shooting and playback. Precise focus checking and a micro-thumbnail display with
up to 81 images are possible. Various coatings are used to insure superior visibility
and durability.
10
Interchangeable unit camera system
Mode dial lock release
Shutter-release button.
Mode dial
Power switch
AF auxiliary light
Flash cover
Hot shoe
Strap eyelet
Alignment mark for
attaching camera unit
Microphone
Up-down dial
Connector
Camera unit
release lever.
playback button
macro button
DIRECT button
OPEN/flash button
VF/LCD button
ADJ. lever
telephoto/
enlarged view button
wide-angle/
thumbnail display
button
Directional pad
MENU/OK button
DISP. button.
Picture display
self-timer/delete button
[ Other functions ]
• Pixel output interpolation algorithm effectively suppresses whiteout.
• Noise reduction increases image quality during high-sensitivity shooting.
Distortion correction reduces the distortion that is characteristic of
wide-angle lenses.
*Done on certain camera units only.
• Level compensation adjusts contrast and tone gradations after shooting.
• Pre-AF speeds up focusing.
• AE/AF target selection provides greater freedom in framing and
creative use of light.
Auto bracketing and white balance bracketing enhance shooting certainty.
• Color bracketing simultaneously records black and white and tinted
monochrome images, each with a different feel.
• Manual flash amount enables the control of subject and background
light balance.
• Tilt indicator supports quick and accurate camera leveling.
• Flag function enables registration of up to 20 images for easy viewing later.
• Grid guide function provides three patterns for selection to suit the subject.
Flexible response to creative intent. Settings read when camera
unit attached
Precise focus checking with a 920,000-dot picture display
Intuitive operation. 8-Directional pad handles diagonal movement
Three My Settings and the My Settings Box
Direct operability. ADJ. lever and two Fn buttons
Shooting functions and operability
(common to both camera units)

Other manuals for Ricoh GXR

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh GXR and is the answer not in the manual?

Ricoh GXR Specifications

General IconGeneral
Megapixel10 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Image stabilizerYes
Image sensor size- \
Maximum image resolution4288 x 2848 pixels
Still image resolution(s)-
InterfaceUSB 2.0, NTSC, HDMI
Minimum RAM512 MB
Minimum processor500 MHz
Camera shutter speed- s
Minimum storage drive space160 MB
Compatible operating systemsWindows 2000/XP/Vista/7, Mac OS 9.0-9.2.2/X 10.1.2-10.6.4
Focal length (35mm film equivalent)- mm
Optical zoom3 x
Auto focusing (AF) modesContrast Detection Auto Focus, Multi Point Auto Focus, Spot Auto Focus
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
Flash modesManual, Red-eye reduction, Slow synchronization
Internal memory84 MB
Compatible memory cardsSD, SDHC
HD typeNot supported
Video formats supportedAVI
Maximum video resolution1280 x 720 pixels
Display diagonal3 \
Display resolution (numeric)920000 pixels
PictBridgeNo
USB version2.0
Scene modesNight, Portrait, Sports, Landscape (scenery)
Image editingresizing, rotating
Camera playbackmovie, single image
Self-timer delay2 s
Playback zoom (max)16 x
Product colorBlack
Battery typeDB-90
Storage temperature (T-T)3648 x 2736 °C
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth37.5 mm
Width113.9 mm
Height70.2 mm
Weight160 g
