With wide focal length coverage in a single lens, the 24-72 mm 3x optical zoom
can handle a diverse range of subjects. The lens configuration has 7 groups and 11
elements, and the rear focus technique convenient for fast AF is used.
Beginning with a large-diameter aspherical lens as the first element, there are a
total of four aspherical lens elements situated in optimum positions. Using special
low-dispersion glass and other techniques, we have achieved suppressing image
distortion and color fringing near the edge, even at 24 mm wide-angle. With an
extravagant optical design, compact size is maintained while achieving high-
resolution and contrast at all focal lengths. In production, the lens group optical
axis and image sensor gradient are precisely adjusted in micron units. Superior
optical performance to the edge of the image is insured before the image is deliv-
ered to the photographer.
Close-up photography with a minimum shooting distance of 1 cm (wide-angle;
distance from front of lens) is possible. When used in combination with the digital
zoom, which provides greater magnification than standard shooting, it is possible
to fill the frame with a subject of about 4.4×3.3 mm size.
Because it can achieve both high image quality and the portability needed for a
photographer's "everyday" zoom lens, a 1/1.7-inch CCD is used as image sensor.
Providing both high-sensitivity and low-noise, this CCD can handle the wide sensi-
tivity setting range of ISO100 to 3200. Even when shooting at high ISO sensitivity,
it is possible to obtain natural high-quality images with low levels of both color
noise and luminance noise.
RICOH LENS S10 24-72 mm uses the Vibration Correction function developed
independently by Ricoh. It is effective for preventing the camera shake that can
occur in various situations, such as when you want an ambient-light atmosphere
for sunset or party scenes, when shooting in museums and other public facilities
where flash use is prohibited, when shooting nightscapes beyond flash range, and
when shooting dark scenes with medium telephoto. In addition, blurring from both
camera shake and subject movement can be suppressed using Auto-Hi (high sensi-
tivity auto), which can be set as high as ISO3200.
8
For a diverse range of photo subjects.
"Everyday" zoom coverage from wide-angle to medium telephoto.
Camera unit
Lens Unit
RICOH LENS S10 24-72mm F2.5-4.4 – Other Major Specifications
The "VC" designation indicates that this unit has the Vibration Correction function
developed independently by Ricoh.
VGA movies
640×480P
Item Specifications
Focal length
Aperture(f-number)
Focus range
Construction
Approximately 10.0 million
1/1.7" CCD (total pixels: approx. 10.40 million)
5.1mm – 15.3mm (35 mm format equivalent: 24-72 mm)
f/2.5 – f/4.4
Normal shooting: Approx. 30 cm to infinity:Macro shooting: Approx. 1 cm to infinity (wide angle); Approx. 4 cm to infinity (telephoto); approx. 1 cm to infinity (zoom macro)
11 el e m e n t s in 7 group s
3.0 × optical zoom; 4.0 × digital zoom; approx. 5.7 × auto resize zoom (VGA)
Auto, Auto-Hi, ISO 100, ISO 200, ISO 400, ISO 800, ISO 1600, ISO 3200
Photographs: 1/2000 180 sec. Movies: 1/ 30 1/2000 sec.
Noise Reduction off: 5 pictures, Noise Reduction on (Weak or Strong): 4 pictures (ISO sensitivity: ISO 800,
ISO 1600, ISO 3200)
Photographs: 3648 × 2048, 3648 × 2736, 3648 × 2432, 2736 × 2736, 3264 × 1840, 3264 × 2448,
3264 × 2176, 2448 × 2448, 2592 × 1944, 2048 × 1536, 1280 × 960, 640 × 480
Movies: 640 × 480, 320 × 240
Based on CIPA standard DB-90: approx. 410 shots
68.7 mm × 57.9 mm × 38.6 mm (excluding projections) When mounted on the camera body:
113.9 mm × 70.2 mm × 44.4 mm (excluding projections)
Camera unit only: Approx. 161g Mounted on camera body: Approx. 325g (not including battery,
SD memory card, or neck strap), accessory weight: approx. 23g (battery, strap)
Effective pixels
Image sensor
Lens
Zoom
ISO sensitivity (Standard Output Sensitivity)
Shutter speed
Number of picture shot in Continuous
Continuous shooting
capacity
Battery life
Dimensions
(W × H × D)
Weight
Excellent correction of various types of aberrations. Sharp optical
performance at all focal lengths
Distinct images without blurring.
Camera shake correction and high-sensitivity setting
Approach subject detail from 1 cm range. Close-up photography
High-sensitivity CCD achieves natural and high image quality
10.00
megapixels
CCD
1/1.7-inch
24-72mm
optical zoom
1cm
minimum shooting distance
Max 5 frames
RAW continuous shooting
Camera Unit
MTF curve graph
Distance from frame center(mm)
(1m F2.5)
01.42.32.83.23.74.14.6
100
80
60
40
20
0
Blue lines:50/mm
Red lines:150/mm
Solid lines:Radial values
Dotted lines:Tangential values
MTF(%)
