• Duplex Motor :
This drives the paper exit roller and the duplex roller.
• Transport/Fusing Motor:
This drives the fusing unit, paper feed roller, registration roller and paper exit roller via the paper
feed clutch, registration clutch and gears.
• Registration Clutch:
This transfers drive from the transport/ fusing motor to the registration roller.
• Paper Feed Clutch:
This transfers drive from the transport/ fusing motor to the paper feed roller.
• Agitator Motor:
This moves the agitators in the waste toner bottle.
• ITB Contact Motor:
This moves the ITB into contact with and away from the color OPCs.
