4. Extender
Pull this extender out when loading sheets larger than A4 , 8
1
/
2
× 11 in the bypass tray.
5. Vents
Prevent overheating.
6. Lower right cover
Open this cover when a paper jam occurs.
7. Right cover
Open this cover when a paper jam occurs.
Rear and left view
1. Vents
Prevent overheating.
Guide to Components (mainly North America)
• Do not obstruct the machine's vents. Doing so risks fire caused by overheated internal
components.
Guide to Names and Functions of Components
33
