Ricon K Series User Manual

32DSSK03.B
2 - 8
 LIFT CYCLE COUNTER
Refer to Figure 2-10. The cycle counter is located inside the hydraulic pump housing and is
visible through a slot on the rear side. The counter advances each time the platform moves
through a complete cycle, which consists of the platform moving from the vehicle floor to the
ground and back to the floor. The number of cycles displayed is used to schedule maintenance
operations.
CYCLE
COUNTER
FIGURE 2-10: CYCLE COUNTER
