RIDGID OF45175A - Motor Specifications and Electrical Requirements; Power Supply and Motor Specifications; General Electrical Connections

The A-C motor used on this compressor
is a capacitor start, capacitor run non-
reversible induction type, having the fol-
lowing specifications. It is wired at the
factory for operation on 110V-120V AC,
60 Hz service.
Voltage 110-120
Amperes 14
Hertz (Cycles) 60
Phase Single
RPM 3450
Motor Specifications and
Electrical Requirements
7
Power Supply and Motor Specifications
To reduce the risk of electrical
hazards, fire hazards or dam-
age to the tool, use proper cir-
cuit protection. Your tool is
wired at the factory for opera-
tion using the voltage shown.
Connect tool to a power line
with the appropriate voltage
and a 15-amp branch circuit.
Use a 15-amp time delay type
fuse or circuit breaker. To
reduce the risk of shock or fire,
if power cord is worn or cut, or
damaged in any way, have it
replaced immediately.
!
WARNING:
General Electrical Connections
To reduce the risk of electrocu-
tion:
1. Use only identical replace-
ment parts when servicing.
Servicing should be per-
formed by a qualified techni-
cian.
2. Do not use in rain or where
floor is wet. This tool is
intended for indoor residen-
tial use only.
!
DANGER:
Do not permit fingers to touch
the terminals of plug when
installing or removing the plug
to or from the outlet.
!
WARNING:
