PERFORMER Digital Partyline, User Manual, Version 2.30
4.4 Specifications
Electrical Properties Values
Audio bandwidth: 50 Hz – 20 kHz
Audio bandwidth (DPL): 50 Hz – 10 kHz
Resolution: 16 bit
Microphone Preamp:
Mic input impedance 1.6 kOhm
Dynamic mic input level -52 dBu
Electret mic input level -38 dBu
Frequency response 80 Hz to 12 kHz, ± 3 dB
Headphone Amplifier:
Load impedance 24 to 600 Ohms
Max. output level 16 Volts peak-to-peak
Max. output power 160 mW @ 200 Ohms
Frequency response 80 Hz to 12 kHz, ± 3 dB
Signal-to-noise-ratio > 82 dB (A)
Power Supply:
Power requirements +48 VDC
Power consumption 60 mA @ 48 V
Dimensions:
H x W x D 76 (3) x 255 (10) x 220 mm (9 inch)
Mass 1300g (2,9 lb.)
Page 31
