What to do if Riedel Performer CD-2 Intercom System device does not start?
If your Riedel Intercom System device isn't starting, the issue might stem from a defective cable, exceeding the maximum cable length, or insufficient voltage on the line. As a solution, check the cable, cable length, and power supply.
Why is there crackling and static on my Riedel Intercom System partyline?
Crackles and static on the partyline can be caused by a defective cable, exceeding the maximum cable length, or insufficient voltage on the line. To resolve this, check the cable, cable length, and power supply.
How to fix low audio in headset on Riedel Performer CD-2 Intercom System?
If the audio in your headset is not loud enough, the problem might be due to an incorrect microphone configuration (dynamic/electret). You should verify the type of microphone you're using and adjust the DIP switch on the C3 beltpack accordingly.
What to do if C3 cannot talk on Riedel Intercom System partyline?
If the C3 beltpack cannot transmit audio on the partyline, it might be because DIP switches 3 and 4 are in the ON position, which disables speaking on the partyline. Check the DIP switches 3 and 4 and turn them OFF if necessary.
What to do if C3 cannot talk or listen on Riedel Intercom System?
If the C3 beltpack cannot transmit or receive audio, it might be because DIP switch 8 is in the ON position, which activates the side tone mode. Check DIP switch 8 and turn it OFF if necessary.
What causes no audio signal from intercom matrix to Riedel Intercom System partyline?
The absence of an audio signal from the intercom matrix to the partyline suggests an incorrect configuration of the intercom matrix. As a solution, check the configuration of the intercom system (Director) and inspect the cable connecting the matrix to the partyline.
What does it mean when the C3 / CW-2 Error LED flickers on Riedel Intercom System?
When the C3 / CW-2 Error LED flickers, it indicates a defective cable or that the maximum cable length has been exceeded. To solve this, check the cable and its length.
Initial setup steps for the CR-4/CR-2 master station, including connections.
Detailed description of front panel controls and connectors on the CR-4/CR-2.
Detailed description of rear panel connectors and DIP switches on the CR-4/CR-2.
Detailed description of front panel controls and connectors on the CD-2.
Detailed description of rear panel connectors and DIP switches on the CD-2.
Description of top panel controls, LEDs, and knobs on the C3 beltpack.
Description of bottom panel connectors and DIP switches on the C3 beltpack.
Detailed description of front panel controls, LEDs, and connectors on the CW-2.
Description of upstream port, power, and data LEDs on the C31.
Description of front panel LEDs, XLR, and analog connectors on the C44/C44plus.
Description of rear panel connectors like Power, Serial, GPIO, and I/O ports.
General| Channels | 2 |
|---|---|
| Power | 12V DC |
| Signal-to-Noise Ratio | > 70 dB |
| Connectors | RJ45 |
| Headset Connector | XLR |
| Power Supply | External Power Supply |
| Power Consumption | Approx. 5W |
| Operating Temperature | 0°C to 50°C |
