Riello C9324400 - Electrical Data

Technical description of the burner
7
20028248
3.3 Electrical data
Tab. C
Tab. D
Tab. E
Model RS 70/E
RBNA Code C9324400 C9324400 C9324401
Control circuit power supply V/Ph/Hz 120/1/60
Main power supply V/Ph/Hz 208-220/3/60 460/3/60 575/3/60
Fan motor IE2/EPACT rpm
HP
V
A
3400
1.5
208 - 230
4
3400
1.5
460
2
3400
1.5
575
1.6
Ignition transformer V1 - V2
I1 - I2
120 V - 1 x 8 kV
1.6 A - 20 mA
Electrical power consumption W max 1350
Electrical control circuit consumption W 750
Total electrical consumption W 2100
Electrical protection NEMA 1
Model RS 100/E
RBNA Code C9325400 C9325410 -
Control circuit power supply V/Ph/Hz 120/1/60
Main power supply V/Ph/Hz 208-220/3/60 460/3/60 575/3/60
Fan motor IE2/EPACT rpm
HP
V
A
3500
3
208 - 230
7.8
3500
3
460
3.9
3500
3
575
3.1
Ignition transformer V1 - V2
I1 - I2
120 V - 1 x 8 kV
1.6 A - 20 mA
Electrical power consumption W max 2600
Electrical control circuit consumption W 750
Total electrical consumption W 3350
Electrical protection NEMA 1
Model RS 130/E
RBNA Code C9326400 C9326400 tbd
Control circuit power supply V/Ph/Hz 120/1/60
Main power supply V/Ph/Hz 208-220/3/60 460/3/60 575/3/60
Fan motor IE2/EPACT rpm
HP
V
A
3500
3
208 - 230
7.8
3500
3
460
3.9
3500
3
575
3.1
Ignition transformer V1 - V2
I1 - I2
120 V - 1 x 8 kV
1.6 A - 20 mA
Electrical power consumption W max 2600
Electrical control circuit consumption W 750
Total electrical consumption W 3350
Electrical protection NEMA 1
