REPLACING THE BATTERY

DIALOG VISION RACK

1. Remove the front panel of the UPS by pulling with both hands.

2. Disconnect the UPS battery cable.

3. Undo the screws securing the support to the UPS and remove the plate securing the batteries.

4. Remove the batteries on a flat surface.

5. Insert the new batteries in the UPS.

6. Screw the battery support and reconnect the cable.

7. Replace the front panel of the UPS.
