Riello RS 28/E - Packaging - Weight; Burner Dimensions; Standard Equipment

20044359
8
GB
Technical description of the burner
3.5 Packaging - weight
The burners are skid mounted. Outer dimensions of packaging are
indicated in (Tab. D).
The weight of the burner complete with packaging is indicated in
(Tab. D).
Tab. D
3.6 Burner dimensions
The maximum dimensions of the burners are given in (Fig. 3).
Inspection of the combustion head requires the burner to be
opened and the rear part withdrawn on the slide bars.
The maximum dimension of the burner when open, without casing,
is give in measurement H.
Tab. E
(1)
Blast tube: short - long (obtainable with the kit)
3.7 Standard equipment
Gas train flange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Flange gasket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Washers for screws . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 4
Flange fixing screws. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 4
Instruction manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
inch A B C lbs
RS 28/E
47
1
/
4“
23
5
/
8“
27
31
/
32“
152
RS 38/E
47
1
/
4“
23
5
/
8“
27
31
/
32“
154
Fig. 2
D36
inch ABC
D
(1)
EFGH I LM
RS 28/E
25
31
/
32”
20
7
/
32”
26
3
/
4”
8
1
/
2”
- 13
15
/
16”
5
1
/
2”
13
5
/
16”
6
7
/
16”
37
7
/
32”
4
1
/
4”
6
5
/
8”
1
1
/
2”
RS 38/E
25
31
/
32”
20
7
/
32”
26
3
/
4”
8
1
/
2”
- 13
15
/
16”
5
1
/
2”
13
5
/
16”
6
7
/
16”
37
7
/
32”
4
1
/
4”
6
5
/
8”
1
1
/
2”
DG
C
M
L
E
F
I
A
B
H
D10233
Fig. 3
