118
2
Kinds of parameters and the number size selection area
IO status, analog IO values analog flags and blocks can be inserted into
LCD for displaying.
3
"Blocks" area
Shows a list of all the circuit program blocks and their parameters.
4
Language selection
5
Animate option
This option is used to the animate display on ELC-43TS, you can refer to
the user instruction of ELC-43TS.
6
"Insert" button
Button for inserting a parameter selected from the “Block parameters”
area.
"Block parameters" or "General parameters" area into the message
text.
7
"Block parameters" area
Shows the parameters of a block selected from the "Blocks" area which you
can output in the message text.
8
"General parameters" area
Shows general parameters such as the current date.
9
"Delete" button
Button for deleting entries from the "Messages" area
"Special characters" button
Button for inserting special characters in the "Messages" area
10
"Messages" area
You arrange the message text in this area. Information entered in this area
corresponds with that on the xLogic display.
To arrange the message text
From the "Blocks" area, select the block whose parameters you want to output.
Drag and drop the parameters required from the "Block parameters" to the "Messages" area. You may
also use the "Insert" button to do so.
In the "Messages" area, you can add parameter data as required.
