Digital input
Block in
xLogicsoft:
Type:(1x)
(Configuration in Text panel
software)
MODBUS code:
02
EXM-12/ELC-12(CPU):0～7
EXM-E-8(EXT1):8～15
EXM-E-8(EXT2):16～23
EXM-E-8(EXT3):24～31
∙
∙
EXM-E-8(EXT8):64～71
PR-6(CPU):0~3
PR-12:0～7
PR-14(CPU):0～9
PR-18(CPU):0～11
PR-E-16(EXT1):12～19
PR-E-16(EXT2):20～27
PR-E-16(EXT3):28～35
∙
∙
PR-E-16(EXT9):76～83
PR-E-16(EXT10):84～91
∙
∙
PR-E-16(EXT15):124～131
PR-E-16(EXT16):132～139
PR-24(CPU):0～13
PR-E-16(EXT1):16～23
PR-E-16(EXT2):24～31
PR-E-16(EXT3):32～39
∙
∙
PR-E-16(EXT9):80～87
PR-E-16(EXT10):88～95
∙
∙
PR-E-16(EXT15):128～135
PR-E-16(EXT16):136～143
BIT
R
