358
Digital outputs
(0x)
MODBUS code:
01(read)
05
(single Write)
15
(Multiple Write)
EXM-12/ELC-12(CPU):0～7
EXM-E-8(EXT1):8～15
EXM-E-8(EXT2):16～23
EXM-E-8(EXT3):24～31
∙
∙
EXM-E-8(EXT7):56～63
EXM-E-8(EXT8):64～71
PR-6(CPU):0～1
PR-12(CPU):0～3
PR-14(CPU):0～3
PR-18(CPU):0～5
PR-E-16(EXT1):8～15
PR-E-16(EXT2):16～23
PR-E-16(EXT3):24～31
∙
∙
PR-E-16(EXT9):72～79
PR-E-16(EXT10):80～87
PR-E-16(EXT11):88～95
PR-E-16(EXT12):96～103
∙
∙
PR-E-16(EXT15):120～127
PR-E-16(EXT16):128～135
PR-24(CPU):0～9
PR-E-16(EXT1):10～17
PR-E-16(EXT2):18～25
PR-E-16(EXT3):26～33
∙
∙
PR-E-16(EXT9):74～81
PR-E-16(EXT10):82～89
∙
∙
PR-E-16(EXT15):122～129
PR-E-16(EXT16):130～137
BIT
R/W
