35mA (265V ac)
4 W (28.8V dc)
Protection against polarity
inversions
Yes
Yes
The main frequency range
47-63Hz
---
Input parameters:
Input No
8 ( I1-I8 )
8 (I1-I8 )
Digital input
8 ( I1-I8 )
8 (I1-I8 )
Analogue input
None
4 ( I1-I4)(0..10V DC)
Input voltage
AC0-240V
DC 0-28.8V
Input signal0
AC0-40V；<0.03mA
< 5V DC;<0.1mA(I1-I4),<1mA(I5-I8)
Input signal1
AC79-240V；
>0.06mA
> 8 V DC;>0.3mA(I1-I4),>1.7mA(I5-I8)
Input current
---
0.4mA(I1-I6),2.3mA(I7-IC),@ 10.8V dc
0.5mA(I1-I6),2.6mA(I7-IC),@ 12.0 V dc
1.2mA(I1-I6),5.2mA(I7-IC),@ 24 V dc
1.5mA(I1-I6),6.3mA(I7-IC),@ 28.8 V dc
Input Response Time
Delay time at 0 to 1：
120V AC ：Typ. 50 ms
240V AC ：Typ. 30 ms
Delay time at 1 to 0：
120V AC ：Typ. 90 ms
240V AC ：Typ.100 ms
Delay time at 0 to 1 ：
Typ. 1.5 ms (I1-I4),<1ms(I5-I8)；
Delay time at 1 to 0 ：
Typ. 1.5 ms(I1-I4),<1ms(I5-I8)；
Maximum counting
frequency
Typ. 4Hz
Typ.：4 HZ
Sensor type
Contact or 3-wire PNP
Contact or 3-wire PNP
Isolation between power
supply and inputs
None
Resistive
Isolation between inputs
None
None
Protection against polarity
inversions
Yes
None
Inputs used as analog inputs( I1-I4 )
Measurement range
---
DC 0---10V
Input impedance
---
Min, 24KΩ ; Max. 72KΩ
Input voltage
---
28.8 V DC max
Resolution
---
10bit ,0.01V
Accuracy at 25 °C
---
± (Max.0.02)V
Accuracy at 55 °C
---
± (Max.0.04)V
Isolation between analog
channel and power supply
---
None
Cable length
---
10 m max. shielded and twisted
Output parameters:
Output No.
4 (Q1-Q4)
Output type
Relay output
Continuous current
Resistive load 10A/Inductive load 2A (Relay)
