Rigaku 4364F501 - SPECIFICATIONS

- 2 -
ME14003C
2. SPECIFICATIONS
(1) Target diameter : 99 mm (drum OD)
(2) Rotational speed : 150 s
-1
(9000 rpm)
(3) Weight : About 5 kg
(4) Drive system : Direct drive by built-in motor
(5) Kind of target
Target material Catalog number
Cu
Cr
Mo
4364F501
4364B501
4364G501
Table 1
(6) Maximum permissible load
Target material
Maximum
permissible
voltage (kV)
Focus size
(mm
2
)
Maximum permissible
load (kW)
The values in the
parentheses are optimum
loads.
Cu 60
0.07 × 0.7
1.2 (40kV-30mA)
Cr 40
0.07 × 0.7
1.0 (35kV-28mA)
Mo 60
0.07 × 0.7
1.2 (50kV-24mA)
Table 2
