Attachment bases are used in combination with attachment heads and sample plates
on the univer
sa
l Z attachment platform.
For
details, refer to the instruction manual
of
each attachment base.
Mounting attachment base to the goniometer
To install the attachment bases
on
th
e universal Z attachment platform, follow
the steps below.
1 Slide the
attachment
base down the rail
of
the universal Z platform.
2 Make
sure
that
the attachment base is level,
and
then secure
it
by
tightening a lever
on
the side
of
the universal Z
attachment
platform .
•
In
stallation
of
attachment
bases
3 Connect the
attachment
base cable to the
attachment
connection
port
of
SmartLab.
G)
Raise the attachment connection port cover to open.
® Connect the cable, with the indication "ATTACHMENT" s
id
e
upward.
@ Tighten the two screws
of
th
e connector.
@ Lower the attachment connection port cover to close.
SmartLab S
E:
Automated Multipurpose X-ray D
iff
ractometer
75
