RIGOL Chapter 1 Quick Start
1-6 DL3000 User’s Guide
Displays the manufacturer, device model, software and
hardware versions, FPGA version, boot version, system boot
times, calibration date, and product serial number.
Reset
Restores the instrument settings to its factory default
settings, For default settings, refer to Table 2-3.
(3) Advanced function key
Provides advanced functions. Currently, the factory test function
and CC+CV function are supported.
(4) Storing and recalling operation key
Saves, reads, deletes, copies, and pastes the files. The
instrument provides an internal non-volatile memory ("Disk C")
and supports an external memory ("Disk D"). A maximum of 100
files can be stored in the instrument.
(5) Help key
Enters the built-in help system. You can view relevant help
information for any key or menu key on the front panel.
5. Knob
(1) Switch the parameters or parameter values.
(2) Increases (rotate clockwise) or decreases (rotate counterclockwise) the
value at the cursor.
Note: Rotating the knob in different interfaces can produce different operation
results. Here introduces its common usage. For other specific usages and
operation methods, refer to details in relevant chapters.
6. Input Control Keys
(1) Input on/off key
Enables or disables the sink function of the load.
(2) Transient trigger key
Turns on or off the transient trigger function.
(3) Short-circuit key
Enables or disables the short circuit function of the load.
